WisuAlarm HY-C102-4 Conventional 4 Zone Fire Alarm Control Panel

WisuAlarm HY-C102-4 Conventional 4 Zone Fire Alarm Control Panel

What is Conventional Fire Alarm System?

The fire alarm system consists of different devices such as heat and/or smoke detectors, and manual call points/pull stations, sounder strobe, which signal to a control panel that a fire has been detected and then alerts building occupants to evacuate through audible and/or visual signaling devices.

Various Communication Interfaces

Seamlessly integrate with various communication interfaces, include Ethernet, RS 232, GND, RS 485, alarm bell power supply, and external power supply, giving you the flexibility to customize your system for smooth integration.

Two-wire and Non-polarity Tech

The system uses advanced Two-Wire Technology, making wiring a simple and cost-effective solution for your projects.

Compatible with Dahua DSS PRO Platform

Manage your CCTV cameras and fire alarms together, eliminating complex multiple platforms which helps improve your overall security infrastructure.

• Record and export capacity of historical events for each of fire, fault and operation
• RS-485 interface contributes to convenient integration
• 90VAC to 240VAC main power supply ensures the stable operation
• Ethernet interfaces enables communication with IoT platform
• 4 dry contacts make connection flexible

Specifications:

Number of Zones: 4

Zone Capacity: 32 detectors per zone

Main Power: AC90-240V/50Hz, 60Hz

Backup Power: 2 lead-acid batteries (12V/2.5Ah each)

Fire Bell Output: DC 28V/500mA

Dimensions: 310.0 mm×73.0 mm×227.0 mm

Weight: 3.5 kg / 5 kg (with 2 batteries)

Operating Temperature: –10°C to +50°C

Operating Humidity: ≤ 95% RH (no condensation)

Protection Grade: IP30

Installation: Wall mount

Compliance Standard: EN54-2, EN54-4
