Ubiquiti Wi-Fi 5 Speaker Amplifier UPL-AMP-B-EU

Ubiquiti Wi-Fi 5 Speaker Amplifier UPL-AMP-B-EU

The Ubiquiti UPL-Amp-B is a high-end WiFi 5 speaker amplifier, equipped with dual Gigabit Ethernet ports, designed for exceptional multi-zone audio streaming and rich spatial sound. It supports low-latency wireless streaming via Apple AirPlay 2 and Spotify, delivering 130W per channel at 8 ohms. The device includes two speaker terminal outputs with custom-designed banana plugs, an RCA analog subwoofer output, and dual RCA analog inputs for left and right channels. Additionally, it features an HDMI eARC input for Dolby Atmos-powered immersive sound and a 1.43" touchscreen rotary knob for intuitive control.

Specifications

Dimensions: 217 x 236.8 x 63.7 mm

Weight: 2.4 kg

Enclosure Material: Plastic

Mounting: Desktop

Colour: Black

Networking Interface: (2) Gigabit Ethernet RJ45 ports

Wi-Fi Standards: 802.11 a/b/g/n/ac

Connectivity: Wi-Fi 2.4 GHz (20/40 MHz); Wi-Fi 5 GHz (20/40/80 MHz)

Power Method: Universal AC input, 100–240V AC, 2.5A Max., 50/60 Hz

Power Consumption: 17W

LEDs: LED ring

LCM Display: 1.43" rotary knob with touchscreen

Button: Factory reset

Operating Temperature: -5 to 40°C

Operating Humidity: 5 to 90% noncondensing

Certifications: FCC, IC, CE

Per Channel Power (Continuous): 130W at 8Ω, 1 kHz, <0.05% THD+N; 260W at 4Ω, 1 kHz, <0.09% THD+N

Amplifier Class: Class D

Output: Mono/Stereo sound

Surround Format Support: Dolby Atmos, Dolby TrueHD, Dolby Digital Plus, Stereo PCM, Multichannel PCM

Grouping: Supports up to 32 PowerAmps

Audio Inputs: (1) HDMI eARC input; (2) RCA analog inputs (L/R)

Audio Outputs: (1) RCA analog subwoofer output; (2) Speaker terminal outputs with included banana plugs

Streaming Support: Apple AirPlay 2, Spotify Connect, Soundtrack Your Brand
