Ubiquiti UniFi Dream Machine Beast 8x10G Ethernet 2SFP28 2SFP+ Cloud Gateway UDM-BEAST

Ubiquiti UniFi Dream Machine Beast 8x10G Ethernet 2SFP28 2SFP+ Cloud Gateway UDM-BEAST

The Ubiquiti UniFi Dream Machine Beast UDM-Beast is a hyperscale-class 1U Cloud Gateway engineered for large, high-performance UniFi deployments. Delivering up to 25Gbps IDS/IPS throughput and supporting more than 7,500 simultaneous client devices, it combines high-speed routing, advanced security, UniFi application hosting and expandable Protect storage in a single rackmount platform. Extensive 25G, 10G and Gigabit connectivity, support for 750+ managed UniFi devices and high-availability gateway failover make it suitable for demanding enterprise and large-scale network environments.

Key Features

• Hyperscale-class 1U UniFi Cloud Gateway.
• Up to 25Gbps IDS/IPS throughput.
• Supports 7,500+ simultaneous connected clients.
• Supports 750+ managed UniFi devices.
• Runs UniFi Network, Protect, Access, Talk and Connect.
• 2 × 25G SFP28 interfaces.
• 2 × 10G SFP+ interfaces.
• 8 × multi-gigabit 10GbE RJ45 interfaces.
• 2 × 1GbE RJ45 interfaces.
• Supports up to 8 WAN ports.
• Integrated 128GB SSD with dual 3.5-inch storage bays.
• Supports Shadow Mode gateway failover for high availability.

25Gbps IDS/IPS Performance

The Dream Machine Beast is designed for extremely high-throughput secured networking. Ubiquiti rates the platform for up to 25Gbps IDS/IPS throughput, allowing intrusion detection and prevention functionality to remain active across high-bandwidth network connections.

Built for Large-Scale UniFi Deployments

The UDM-Beast supports more than 7,500 simultaneous connected clients and over 750 managed UniFi devices. It can also manage up to 200 UniFi Access Hubs, making it suitable for large campuses, enterprises and other high-density deployments requiring centralised UniFi management.

Full UniFi Application Platform

UniFi Network, Protect, Access, Talk and Connect can be hosted directly on the gateway. This consolidates network management, video surveillance, access control, communications and compatible UniFi applications onto a single high-performance platform.

25G and 10G Connectivity

High-bandwidth connectivity includes two 25G SFP28 ports, two 10G SFP+ ports and eight 10GbE RJ45 interfaces supporting 10G, 5G, 2.5G, 1G and 100Mbps operation. Two additional Gigabit Ethernet RJ45 ports are provided for standard wired connectivity.

Flexible Multi-WAN Architecture

The default WAN configuration provides one 25G SFP28 interface and one 10GbE RJ45 interface. The platform supports configuration of up to eight WAN connections, providing flexibility for multi-provider internet connectivity, redundancy and sophisticated enterprise routing deployments.

Expandable UniFi Protect Storage

An integrated 128GB SSD provides onboard system storage, while two 3.5-inch drive bays allow additional storage drives to be installed for UniFi Protect. The gateway can manage up to 100 HD cameras, 60 2K cameras or 40 4K cameras, depending on the surveillance configuration.

High-Availability Gateway Support

Shadow Mode with VRRP gateway failover allows compatible deployments to use redundant Dream Machine Beast gateways for increased network availability. DC power backup support provides an additional redundancy option when used with compatible Ubiquiti power infrastructure.

1U Enterprise Rackmount Design

The Dream Machine Beast fits into a standard 1U rack space and measures 442.4 × 43.7 × 325mm. Its rackmount form factor consolidates routing, security, application hosting and NVR functionality into a single platform for streamlined enterprise infrastructure deployments.

Technical Specifications

What’s in the Box:

• Ubiquiti UniFi Dream Machine Beast UDM-Beast
• Power Cable
• Rackmount Kit
• Footpads

The Ubiquiti UniFi Dream Machine Beast delivers hyperscale UniFi performance in a compact 1U platform. With 25Gbps IDS/IPS throughput, support for 7,500+ clients and 750+ managed UniFi devices, extensive 25G and 10G connectivity, expandable Protect storage and high-availability gateway support, it provides a powerful foundation for large-scale enterprise UniFi infrastructure.
