Ubiquiti UISP airFiber 60 PtP Radio System AF60

SKU: AF60

Price:
R 7,179
Stock:
Sold out

Description

Ubiquiti UISP airFiber 60 PtP Radio System AF60

60 GHz PtP radio system with 5 GHz backup.

The airFiber 60 equipped with a high-gain dish antenna and 5GHz backup radio establishes sustainable PtP links and deliver a 1.9 Gbps throughput rate. It also has a dedicated Bluetooth management radio so it can be set up quickly and fully configured with the UISP® application (web/mobile). It can also be seamlessly integrated into an existing deployment with Ubiquiti’s dedicated link planning platform and tracked from anywhere with its built-in GPS antenna.

Features

  • Low interference 60 GHz radio with 5 GHz backup
  • Link range: up to 2 km
  • Link planning support via ISP Design Center



Technical Specification

Mechanical
Dimensions: 413 x 413 x 320 mm (16.26 x 16.26 x 12.60")
Weight Without Mount: 1.4 kg (3.09 lb)
With Mount: 1.8 kg (3.97 lb)
Enclosure Materials: Aluminum, UV-stabilized Polycarbonate
Mounting: Pole Mount (Included)
Wind Loading: 420 N at 200 km/h (94.4 lbf at 125 mph)
Wind Survivability: 200 km/h (125 mph)

Hardware
Networking Interface: (1) 10/100/1000 Mbps Ethernet Port
Antenna Gain:
  • 5 GHz - 11 dBi
  • 60 GHz - 38 dBi
Max. Power Consumption: 11W
Power Method: Passive PoE, Pins 4, 5+ and 7, 8-
Power Supply: 24VDC, 0.5A Gigabit PoE Adapter (Included)
Voltage Range: +22 to +26VDC
LEDs: Power/Ethernet/5G/60G/GPS
ESD/EMP Protection: ± 24kV Contact/Air
Operating Temperature: -40 to 60° C (-40 to 140° F)
Operating Humidity: 5 to 95% Noncondensing
Certifications: FCC, IC, CE

Radio
Max. Conducted TX Power
  • 5/60 GHz Combined: 25 dBm

Software
OS: airOS®
Maximum Throughput: 1.9 Gbps
Maximum Range: 2+ km
Encryption: WPA2-PSK (AES)/WPA2 Enterprise
