TP-Link Omada 5GHz Long-Range Indoor/Outdoor Wireless Flex Bridge
The Omada Flex Bridge 5 is a flexible 5GHz wireless bridge designed to extend network connectivity between buildings, surveillance installations and remote locations. Delivering wireless speeds of up to 867Mbps and transmission distances of up to 5km under suitable conditions, it supports both point-to-point and point-to-multipoint deployments. Integrated 17dBi directional antennas, three Gigabit Ethernet ports and two PoE Out connections make it particularly well suited to outdoor networking and IP surveillance applications.
Key Features
- 5GHz 802.11ac wireless bridge with speeds of up to 867Mbps.
- Point-to-point and point-to-multipoint wireless bridge support.
- Long-range wireless transmission of up to 5km under suitable conditions.
- Integrated 17dBi high-gain directional antennas with 2×2 MIMO.
- Three Gigabit Ethernet ports, including two PoE Out ports for compatible devices.
- DIP switches simplify role selection and rapid bridge pairing.
- IP66 weatherproof construction with 6kV lightning protection.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | Omada |
| Model | Flex Bridge 5 |
| Product Type | Indoor / Outdoor Wireless Bridge |
| Deployment Modes | Point-to-Point (PtP) / Point-to-Multipoint (PtMP) |
| Wireless Standards | IEEE 802.11a/n/ac |
| Wireless Frequency | 5GHz |
| Maximum Wireless Signal Rate | Up to 867Mbps |
| Wireless Configuration | 2×2 MU-MIMO |
| Maximum Transmission Distance | Up to 5km (3.1 miles) under Suitable Conditions |
| Standard PtMP Capacity | Up to 8 Flex Bridge Nodes |
| PtMP Capacity with Sector Bridge 5 | Up to 32 Flex Bridges |
| 5GHz Antennas | 2 × Internal 17dBi Directional Antennas |
| Antenna Beamwidth | 40° Horizontal / 18° Vertical |
| Ethernet Ports | 3 × Gigabit Ethernet |
| PoE Out Ports | 2 × Gigabit PoE Out |
| PoE Out Power | Up to 10W on One Port / Up to 5W per Port when Both are Used |
| Power Options | 802.3af/at PoE / Passive PoE / 12V DC |
| Maximum Power Consumption | 12W via DC / 26.06W via PoE with PoE Out |
| Pairing Controls | Role Switch / Pairing Code DIP Switch |
| Alignment | LED Signal Indicators / Omada App-Guided Alignment |
| Wireless Features | MU-MIMO / Rate Limit / Wireless Statistics / Scheduled Reboot / RADIUS Accounting |
| Wireless Security | VLAN / Rogue AP Detection / Wireless Encryption |
| Management | Standalone / Omada Central / Omada Hardware Controller / Omada Software Controller |
| Management Interfaces | Omada App / Web-Based Management / SNMP / SSH |
| Cloud Access | Yes, with Omada Controller |
| Weatherproof Rating | IP66 |
| Lightning / ESD Protection | ±8kV Air Discharge / ±4kV Contact Discharge / ±6kV Common Mode |
| Mounting | Pole / Wall |
| Dimensions (W × D × H) | 214.2 × 50.8 × 119.8mm |
| Weight | 0.59kg |
| Operating Temperature | -40°C to 70°C |
| Storage Temperature | -40°C to 70°C |
| Operating Humidity | 10% to 90% RH, Non-Condensing |
| Certifications | CE / FCC / RoHS |
| What's in the Box: |
|
Extend network and surveillance connectivity across outdoor locations with the flexible long-range wireless performance and integrated PoE capabilities of the Omada Flex Bridge 5.
