Description
TP-Link ER8411 Omada VPN Router
Omada VPN Router with 10G Ports
Features
Integrated into Omada SDN
- Zero-Touch Provisioning (ZTP)*, Centralized Cloud Management, and Intelligent Monitoring.
Centralized Management
- Cloud access and Omada app for ultra convenience and easy management.
Quad-Core 2.2 GHz CPU
- Enterprise–level hardware design provides maximum performance
Two 10GE SFP+ Ports
- 1x WAN and 1x WAN/LAN 10GE SFP+ ports provide high-bandwidth aggregation connectivity.
Up to 10 WAN Ports
- Fiber and RJ45 WAN ports with load balance raise the utilization rate of multi-line broadband.
Two USB 3.0 Ports
- Available 4G/3G Modem connection for LTE WAN backup
Highly Secure VPN
- Enterprise-standard SSL/ IPSec / PPTP / L2TP VPN & OpenVPN / L2TP over IPSec VPN are ideal for use across multiple branches and for WFH.
Abundant Security Features
- Powerful Firewall, DoS defense, IP/MAC/URL filtering, and IP-MAC Binding, and One-Click ALG Activation provide world-class security.
Dual Redundant Power Supplies
- Carrier-class reliability for enterprise networking
Technical Specification
Product: TP-Link ER8411 Omada VPN Router with 10G Ports
Standards and Protocols
-
IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q
-
TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, SNMP
Interface ports
-
2x 10GE SFP+ Ports (1 WAN, 1 WAN/LAN)
-
1x 1GE SFP WAN/LAN Ports
-
8x 1GE RJ45 WAN/LAN Ports
-
1x RJ45 Console Ports
-
2x USB Ports (Connecting 4G/3G Modem as WAN Backup)
Network Media
-
10BASE-T: UTP category 3, 4, 5 cable (Max 100 m)
-
EIA/TIA-568 100Ω STP (Max 100 m)
-
100BASE-TX: UTP category 5, 5e cable (Max 100 m)
-
EIA/TIA-568 100Ω STP (Max 100 m)
-
1000BASE-T: UTP category 5e, 6 cable (Max 100 m)
Fan Quantity: 2
Button: Reset Button
Power Supply: Redundant Dual Power Supplies (100–240 VAC, 50/60 Hz)
Flash: 4MB SPI NOR + 256 MB NAND
DRAM: 4 GB DDR4
Protection: 4 kV surge protection
Enclosure: Steel
Mounting: Rack Mountable
Button: Reset Button
Power Supply: Redundant Dual Power Supplies (100–240 VAC, 50/60 Hz)
Flash: 4MB SPI NOR + 256 MB NAND
DRAM: 4 GB DDR4
Protection: 4 kV surge protection
Enclosure: Steel
Mounting: Rack Mountable
Package Contents
-
Omada 10G Multi-WAN Security Gateway ER8411
-
Power Cord
-
Rack-Mount Kit
-
Quick Installation Guide
