Synology RackStation RS2423RP+II 12-Bay NAS Enclosure

Synology RackStation RS2423RP+II 12-Bay NAS Enclosure

Faster and more responsive

The RS2423RP+II offers exceptional performance with over 155K/79K random read/write IOPS and up to 3,500/1,700 MB/s sequential read/write throughput.² They are the perfect cost-effective file management and sharing solution for SMBs and come equipped with advanced backup capabilities designed for businesses with expanding data needs.

Features:

Business-ready

Over 3,500/1,700 MB/s seq. read/write, built-in 10GbE, and up to 240 TB raw storage before expansion.

Flexible configuration

Add 12 extra drive bays, 1/10/25GbE ports, and SSD cache volumes whenever needed.

Versatile applications

Back up 300 endpoints, manage 75 IP cameras, or safely sync and share files between devices and sites.

Designed for reliability

The RS2423RP+II comes with one 10GbE RJ-45 port and two Gigabit RJ-45 ports, which can be bonded with Link Aggregation to enable automatic network failover and load balancing.

Two RS2423RP+II units can be paired using Synology High Availability to form a reliable active-passive server cluster, maximizing service uptime.

The RS2423RP+II also features redundant and hot-swappable power supply units to protect service continuity in case there are issues with one power source.

Room for expansion

Easily adjust the 2U 12-bay RS2423RP+II to match the usage of your environment, whether it needs performance, faster networking, or higher storage capacity.

Versatile storage for businesses

The RS2423RP+II is ideal for small to medium-sized businesses and branch offices seeking a high-performing, reliable, and cost-efficient storage solution for file management, data backup, and surveillance.

Intuitive storage for on-site and remote teams

Provide secure and convenient cross-platform file access, sharing, and synchronization across multiple locations.

Smart and scalable surveillance

Leverage flexible deployment options, intuitive management capabilities, and advanced video analytics to secure your premises.

Simple-to-deploy local surveillance

Wide device compatibility

Connect up to 75 IP cameras from a selection of over 8,600 validated models thanks to Synology Surveillance Station’s wide camera compatibility.

Multi-platform convenience

Monitor live streams or watch recordings from web browsers, desktop clients, or the DS cam mobile app.

Secure and private storage

Footage is stored locally for easier compliance with data protection regulations and further protected from unauthorized access with industry-standard AES-256 encryption.

Flexible monitoring of multiple locations

Assisted camera deployment

Automatically locate new cameras within a set IP range, and configure units in batch via spreadsheet import or replicating settings to new cameras.

Centralized management and monitoring

Stay on top of your deployment by previewing triggered events directly on multi-floor or multi-location maps, with online map integration for Google Maps and OpenStreetMap.

Time-saving video analytics

Take advantage of intelligent monitoring features such as motion detection, no-idle zones, foreign object detection, and anomaly detection that cater to common surveillance scenarios.

Technical Specifications:

Processor

CPU Model
AMD Ryzen V1780B

CPU Quantity
1

CPU Cores
4

CPU Threads
8

CPU Architecture
64-Bit

CPU Frequency
3.35 GHz (Base) / 3.6 GHz (Turbo)

Hardware Encryption Engine
Supported

Memory

Installed Memory
8 GB DDR4 ECC UDIMM

Pre-Installed Memory Configuration
8 GB (1 × 8 GB)

Memory Slots
2

Maximum Memory Capacity
32 GB (2 × 16 GB)

Storage

Drive Bays
12

Maximum Drive Bays With Expansion Unit
24 (RX1223RP × 1)

Supported Drive Types

• 3.5" SATA HDD
• 2.5" SATA SSD

Hot-Swappable Drives
Supported

External Ports

LAN Ports

• 2 × RJ-45 1GbE
• 1 × RJ-45 10GbE

USB Ports
2 × USB 3.2 Gen 1

Expansion Ports
1

Expansion Port Type
Mini-SAS HD

PCIe Expansion

PCIe Slot
1 × PCIe Gen3 ×8 Slot (×4 Link)

System And Cooling

System Fans
3 × 60 mm × 60 mm

Fan Speed Modes

• Full-Speed Mode
• Cool Mode
• Quiet Mode

Easy Replacement System Fan
Supported

Power Recovery
Supported

Scheduled Power On / Off
Supported

Wake On LAN / WAN
Supported

Noise Level
56.2 dB(A)

Power

Power Supply
550 W

Redundant Power Supply
Supported

AC Input Voltage
100 V To 240 V AC

Power Frequency
50/60 Hz, Single Phase

Power Consumption

• 114.86 W (Access)
• 42.33 W (HDD Hibernation)

Heat Dissipation

• 392.18 BTU/hr (Access)
• 144.53 BTU/hr (HDD Hibernation)

Physical Specifications

Form Factor
2U Rackmount

Dimensions (H × W × D)
88 × 482 × 578 mm

Weight
11.9 kg

Rack Installation Support
4-Post 19" Rack (Rail Kit Sold Separately)

Environmental

Operating Temperature
0 °C To 35 °C (32 °F To 95 °F)

Storage Temperature
-20 °C To 60 °C (-5 °F To 140 °F)

Operating Humidity
8% To 80% RH

Storage Humidity
5% To 95% RH

Certifications

Compliance Standards

• FCC
• CE
• BSMI
• VCCI
• RCM
• UKCA
• EAC
• CCC
• KC
• BIS
• UL
• RoHS

Warranty

Warranty Period
3-Year Hardware Warranty (Extendable To 5 Years With EW202)

What's in the Box:

• RackStation RS2423RP+II
• Accessory Pack
• 2 × AC Power Cords
• Quick Installation Guide
