The Shelly Pro Dimmer 0/1-10V PM is a professional DIN-rail smart dimming controller designed to manage compatible 0-10V and 1-10V drivers for lighting, motors, valves and other control applications. Featuring integrated power monitoring, Ethernet, Wi-Fi and Bluetooth connectivity, it provides precise dimming, advanced scheduling and automation for residential, commercial and building-management installations.

Key Features:

• Professional DIN-rail smart dimming controller
• Supports 0-10V and 1-10V current-sourcing control
• Single relay output with power measurement
• Up to 16A switching at 240V AC
• Real-time voltage, current, power and energy monitoring
• Ethernet RJ45 connectivity
• Wi-Fi 802.11b/g/n
• Bluetooth 4.2
• Wi-Fi range extender and BLE gateway functionality
• One-button and dual-button dimming control
• Night Mode
• Basic and advanced schedules
• MQTT, scripting and webhooks support
• KNXnet/IP communication support
• Overheating, overvoltage, overcurrent and overpower protection

Features

0-10V and 1-10V Driver Control

The Shelly Pro Dimmer 0/1-10V PM is a current-sourcing controller designed for compatible 0-10V and 1-10V drivers. It can be used for dimmable lighting as well as other supported control applications such as motors and valves.

Integrated Power and Energy Monitoring

Built-in metering provides detailed information on voltage, current, active and apparent power, active and apparent energy, power factor and fundamental active and reactive energy, helping users monitor the electrical performance of connected loads.

16A Relay Output

In addition to the 0-10V control terminals, the controller incorporates a relay output rated for switching loads up to 16A at 240V AC. The relay also provides integrated power measurement.

Ethernet, Wi-Fi and Bluetooth

RJ45 Ethernet provides reliable wired networking, while Wi-Fi offers flexible wireless connectivity. Bluetooth is used for commissioning and gateway functionality, while the device can also bridge compatible Shelly BLU devices to a Wi-Fi network.

Flexible Physical Dimming Controls

Two switch or button inputs allow the controller to retain existing wall controls. It supports both one-button and dual-button dimming, along with adjustable fade rates, brightness presets and configurable minimum and maximum brightness levels.

Schedules, Night Mode and Automation

Up to 20 schedules can be configured, including advanced routines and sunrise or sunset-based actions. Night Mode can automatically apply a selected brightness level during specified hours, while scripting, MQTT and webhooks support more advanced automation.

Professional Building Integration

KNXnet/IP support allows integration into compatible building-automation environments, while the embedded web interface and compatibility with platforms such as Home Assistant, Alexa, Google Home and SmartThings provide additional control options.

• A neutral connection is required for operation.
• The device controls compatible 0-10V and 1-10V drivers; it is not a conventional phase-cut AC dimmer.
• External circuit protection up to 16A with suitable B or C tripping characteristics is specified by Shelly.
• Installation inside an electrical distribution board should be carried out by a qualified electrician.

Technical Specifications:

Choose the Shelly Pro Dimmer 0/1-10V PM for professional DIN-rail control of compatible 0-10V and 1-10V drivers, with 16A switching, detailed power monitoring, Ethernet networking and advanced local automation for smart lighting and building-control applications.
