ONERugged M14M 14-inch Rugged Tablet - Intel Core Ultra-7 155H 256GB ROM 32GB RAM Win11 Pro OR-M14M-U7-32GB-256GB

ONERugged M14M 14-inch  Rugged Tablet - Intel Core Ultra-7 155H 256GB ROM 32GB RAM Win 11 Pro OR-M14M-U7-32GB-256GB

The ONERugged M14M OR-M14M-U7-32GB-256GB is a high-performance 14-inch rugged Windows tablet designed for industrial, field-service, logistics and other demanding professional environments. This configuration combines an Intel Core Ultra 7 155H processor with 32GB DDR5 memory and a 256GB PCIe SSD, providing substantial computing performance for demanding mobile workloads and local AI applications. A 14-inch 1000-nit Full HD touchscreen, IP65 protection, MIL-STD-810H ruggedisation, dual-battery architecture and extensive industrial I/O make the M14M a powerful mobile workstation for challenging operating environments.

Key Features

• 14-inch high-performance rugged Windows tablet.
• Intel Core Ultra 7 155H processor.
• 16 cores and 22 threads with speeds up to 4.8GHz.
• Integrated NPU for AI-accelerated workloads.
• 32GB DDR5 memory.
• 256GB PCIe SSD storage.
• Windows 11 Pro operating system.
• 14-inch Full HD 1920 × 1080 touchscreen.
• High-brightness 1000-nit sunlight-readable display.
• 10-point capacitive touchscreen with glove support.
• 5MP front and 13MP autofocus rear cameras.
• Wi-Fi 6 wireless connectivity.
• Bluetooth 5.1.
• 4G LTE connectivity with optional 5G capability depending on configuration.
• Integrated GPS.
• Thunderbolt 4 USB-C connectivity.
• Dual Gigabit Ethernet interfaces.
• RS-232 serial interface for industrial equipment.
• Dual-battery architecture with hot-swappable removable main battery.
• Integrated fingerprint reader.
• IP65-rated protection against dust and water.
• MIL-STD-810H ruggedisation.
• Designed to withstand 4ft / approximately 1.2m drops.
• Operating temperature range from -20°C to 60°C.

Intel Core Ultra 7 Performance

This M14M configuration is powered by the Intel Core Ultra 7 155H processor. Its 16-core, 22-thread architecture provides up to 4.8GHz maximum frequency and 24MB cache, giving the rugged tablet the processing resources required for demanding business, engineering and industrial workloads.

Dedicated AI Acceleration

The Intel Core Ultra platform combines CPU, GPU and NPU processing resources to accelerate modern AI workloads. The dedicated NPU enables supported AI tasks to be processed efficiently on the device, making the M14M suitable for edge computing and AI-assisted professional applications where local processing is beneficial.

32GB DDR5 Memory and PCIe SSD

The OR-M14M-U7-32GB-256GB configuration provides 32GB of DDR5 SO-DIMM memory together with a 256GB PCIe SSD. This combination supports demanding multitasking while providing fast local storage for Windows, professional applications and operational data.

14-Inch 1000-Nit Full HD Display

The large 14-inch display provides a Full HD resolution of 1920 × 1080 and brightness of up to 1000 nits, improving screen visibility for outdoor and brightly lit field environments. The 10-point capacitive touchscreen also supports glove operation for practical use in industrial and field-service applications.

Rugged IP65 and MIL-STD-810H Construction

The M14M is built for environments where conventional consumer tablets may not provide sufficient protection. Its IP65 rating provides protection against dust and water ingress, while MIL-STD-810H ruggedisation and documented 4ft drop testing help prepare the tablet for demanding mobile and industrial use.

Dual-Battery Hot-Swap Design

A dual-battery architecture combines a removable high-capacity main battery with a smaller internal battery. The internal battery allows the main battery to be exchanged without immediately shutting down the tablet, helping support longer working shifts and mission-critical applications where interruptions need to be minimised.

Extensive Industrial Connectivity

The M14M provides a broad selection of interfaces for professional and industrial equipment. Connectivity includes USB 3.2, USB 2.0, Thunderbolt 4 USB-C, Mini HDMI, Gigabit Ethernet, RS-232 serial connectivity, microSD and SIM interfaces, a 3.5mm audio connection and a 12-pin pogo interface.

Wireless and Mobile Connectivity

Wi-Fi 6 and Bluetooth 5.1 provide modern local wireless connectivity, while cellular-capable configurations support 4G LTE. A 5G module is available as an optional configuration. Integrated positioning functionality further supports mobile and field-based applications.

Dual-Camera System

An integrated 5MP front-facing camera supports video communication and documentation, while the 13MP autofocus rear camera provides higher-resolution image capture for inspections, evidence collection, asset management and other field workflows.

Industrial Expansion Options

The M14M platform supports additional expansion options for specialised deployments, including an optional 1D/2D barcode scanner and additional PCIe-based expansion. Availability depends on the exact ordered configuration and should be confirmed where these optional modules are required.

Technical Specifications

What’s in the Box:

• 1 × ONERugged M14M Rugged Tablet
• 1 × Handle
• 1 × 19V / 3.78A Power Adapter
• 1 × Warranty Card
• 1 × User Manual

The ONERugged M14M OR-M14M-U7-32GB-256GB combines desktop-class Intel Core Ultra 7 processing with 32GB DDR5 memory, a large 1000-nit touchscreen and industrial-grade rugged construction. Its extensive I/O, dual-battery design, Thunderbolt 4 connectivity and IP65/MIL-STD-810H protection make it a capable mobile computing platform for demanding professional and field environments.
