Minrray UV515-10-IR FHD PTZ Camera

Minrray UV515-10-IR FHD PTZ Camera

The Minrray UV515-10-IR FHD PTZ Camera delivers professional Full HD video performance for video conferencing, education, lecture capture and live streaming. Featuring a 2.07MP CMOS sensor, 10x optical zoom and precise motorised pan-tilt-zoom operation, this camera captures clear 1080p video at up to 30fps. With USB 2.0 connectivity, advanced autofocus, 2D/3D noise reduction and infrared remote control, the UV515-10-IR provides flexible camera operation for professional audiovisual environments.

Key Features:

• Professional Full HD PTZ conference camera
• Model: UV515-10-IR
• 1/2.9-inch high-quality CMOS image sensor
• 2.07MP effective resolution
• 1920 x 1080 Full HD video at up to 30fps
• 10x optical zoom lens
• 10x digital zoom
• Focal length: 4.34mm to 41.66mm
• Viewing angle: 8.8° to 66°
• Fast and accurate autofocus technology
• Automatic and manual white balance
• Advanced 2D and 3D noise reduction
• Smooth and quiet motorised PTZ operation
• USB 2.0 connectivity with UVC support
• H.265, H.264 and MJPEG video compression
• RS232 and RS485 control interfaces
• VISCA, Pelco-D and Pelco-P control protocols
• Up to 255 programmable camera presets
• Infrared remote control support
• Low-power sleep functionality
• Compact black camera design

Features

Professional Full HD Video

The UV515-10-IR captures video at resolutions up to 1920 x 1080 at 30fps. Its advanced image processing delivers detailed video with natural colour reproduction for professional meetings, presentations and educational applications.

2.07MP CMOS Image Sensor

Equipped with a 1/2.9-inch CMOS sensor, the camera provides clear images with consistent colour and brightness. Advanced ISP processing enhances image clarity and overall visual performance.

10x Optical Zoom

The integrated 10x optical zoom lens allows users to capture close-up views of distant subjects while maintaining image detail. Its 4.34mm to 41.66mm focal length provides flexible framing for conference rooms and presentation spaces.

Flexible Viewing Angle

With a viewing angle ranging from approximately 66° at wide-angle to 8.8° at telephoto, the camera supports both wider room views and focused shots of individual speakers.

Smooth and Quiet PTZ Movement

High-precision stepping motors enable smooth pan and tilt adjustments with minimal operating noise. The motorised PTZ system provides accurate positioning during conferences, lectures and recordings.

Fast Autofocus Technology

Advanced autofocus algorithms help maintain image sharpness as the camera changes position or zoom level. Automatic and manual focus controls provide flexibility for different recording environments.

Advanced 2D and 3D Noise Reduction

Integrated 2D and 3D noise reduction technologies help minimise unwanted image noise while preserving detail, improving video clarity in challenging lighting conditions.

USB 2.0 Video Connectivity

The USB 2.0 interface supports UVC video communication for connection to compatible computers and conferencing applications. This simplifies integration into USB-based professional video systems.

Efficient Video Compression

Support for H.265, H.264 and MJPEG video formats provides flexible compatibility with supported software and video processing systems.

Remote PTZ Control

RS232 and RS485 interfaces support remote camera control using VISCA, Pelco-D and Pelco-P protocols. The included infrared remote provides convenient access to camera positioning and preset functions.

Programmable Camera Presets

The camera supports up to 255 preset positions through compatible control systems, with up to 10 presets accessible through the infrared remote control. Presets enable rapid movement between frequently used camera views.

Low-Power Sleep Mode

The integrated sleep function reduces power consumption when the camera is not actively operating, with standby sleep consumption specified below 400mW.

Compact Professional Design

The black housing combines a compact footprint with quiet motorised operation, making the camera suitable for meeting rooms, classrooms, lecture halls and professional audiovisual installations.

Technical Specifications:

What's in the Box:

• 1 x Minrray UV515-10-IR FHD PTZ Camera
• 1 x Power Adapter
• 1 x Infrared Remote Control
• 1 x USB 2.0 Cable
• 1 x User Manual

The Minrray UV515-10-IR FHD PTZ Camera combines 1080p video, 10x optical zoom, quiet PTZ operation and USB connectivity in a compact professional design. Featuring advanced autofocus, noise reduction and remote camera control, it provides flexible video functionality for conferencing, education and professional audiovisual applications.
