Minrray UV510E6-12 2.07MP FHD PoE PTZ Camera

Minrray UV510E6-12 2.07MP FHD PoE PTZ Camera

Capture clear, professional Full HD video with the Minrray UV510E6-12 PTZ Camera. Equipped with a 2.07MP Sony CMOS sensor, 12x optical zoom and 1080p video at up to 60fps, it delivers detailed footage for video conferencing, lecture capture and live streaming. Smooth motorised pan-and-tilt movement, intelligent autofocus and advanced noise reduction ensure reliable performance. HDMI, SDI, USB 2.0, network streaming and PoE connectivity provide flexible integration with professional AV systems.

Key Features:

• 2.07MP Full HD PTZ camera
• 1/2.8-inch Sony CMOS image sensor
• 1920 x 1080 resolution at up to 60fps
• 12x optical zoom and 10x digital zoom
• 70.28-degree maximum horizontal viewing angle
• F1.8 to F2.68 aperture
• Fast and accurate automatic focus
• Advanced image signal processing
• 2D and 3D digital noise reduction
• Automatic exposure and white balance
• Quiet motorised pan-and-tilt movement
• HDMI and SDI video outputs
• USB 2.0 computer connectivity
• Ethernet connectivity with PoE support
• H.264 and H.265 video compression
• Compatible IP video streaming
• RS-232 and RS-422/RS-485 control
• Infrared remote control operation
• Programmable PTZ camera presets
• 12V DC power input

Features

Full HD 1080p Video

The 1/2.8-inch Sony CMOS sensor captures 1920 x 1080 video at up to 60fps through supported outputs, delivering clear footage for meetings, presentations and professional recording.

12x Optical Zoom

The 12x optical zoom lens allows users to capture wide room views and close-up shots of presenters without sacrificing image detail through digital enlargement.

Wide-Angle Coverage

With a horizontal field of view ranging from approximately 6.57 to 70.28 degrees, the camera supports both wider room coverage and more focused subject framing.

Automatic Focusing

Advanced autofocus algorithms help maintain sharp image quality when adjusting zoom levels or switching between subjects at different distances.

Quiet Motorised PTZ

High-precision motors provide smooth pan-and-tilt movement with minimal operating noise, supporting video conferencing and live presentation environments.

Advanced Image Processing

Automatic exposure, white balance and 2D/3D noise reduction help maintain natural colours and improve image clarity under changing lighting conditions.

HDMI and SDI Connectivity

HDMI and SDI outputs allow the camera to connect to compatible displays, video switchers, recorders and professional audiovisual systems.

USB 2.0 Connectivity

The USB 2.0 interface provides a connection to compatible computers and video applications, supporting Full HD capture at frame rates determined by the USB output format.

Power over Ethernet

PoE support allows compatible network equipment to deliver power and data over an Ethernet connection, helping simplify cable management during installation.

Network Streaming

H.264 and H.265 compression support efficient network video transmission for compatible IP streaming and remote video applications.

Flexible Camera Control

Serial control interfaces and infrared remote operation allow users to adjust camera positioning, configure settings and recall stored PTZ presets.

Important Information:

• Model: UV510E6-12.
• This is a Full HD camera, not a 4K model.
• Optical zoom is 12x, with 10x digital zoom.
• USB 2.0 frame rates differ from HDMI and SDI outputs.
• PoE requires compatible network equipment.
• AI tracking is not confirmed for this model.
• NDI is not confirmed for the standard SKU.
• External microphones and video equipment are separate.
• Warranty is subject to regional supplier terms.

Technical Specifications:

What's in the Box:

• 1 x Minrray UV510E6-12 PTZ Camera
• Power Adapter
• RS-232 Control Cable
• Infrared Remote Control
• User Manual and Documentation
