Minrray UV470A2-31 4K Broadcasting PTZ Camera

Minrray UV470A2-31 4K Broadcasting PTZ Camera

Capture professional broadcasts with the Minrray UV470A2-31 4K Broadcasting PTZ Camera. Featuring a 1/1.8-inch 8.42MP Sony CMOS sensor, 31x optical zoom and 4K UHD video at up to 60fps, this camera delivers detailed footage for live streaming, event production and conferencing. Advanced autofocus, AI subject tracking, smooth motorised pan-tilt movement and flexible HDMI, SDI, USB and IP connectivity support professional broadcasting workflows.

Key Features:

• Professional 4K UHD broadcasting PTZ camera
• 3840 x 2160 resolution at up to 60fps
• 1/1.8-inch Sony CMOS image sensor
• 8.42MP effective resolution
• 31x optical and 8x digital zoom
• 6.91–214.64mm focal length
• Fast, accurate automatic focusing
• AI-powered subject tracking and framing
• Face-assisted autofocus
• Smooth, quiet motorised pan and tilt
• Advanced 3D noise reduction
• HDMI and SDI video output options
• USB-C and Gigabit LAN connectivity
• H.264/H.265 network video compression
• RTSP, RTMP, SRT and ONVIF support
• Optional NDI|HX3 integration
• PoE+ support on compatible configurations
• RS-232 and RS-422/485 camera control
• Up to 255 camera presets
• Integrated tally status indicator
• MicroSD recording support
• Infrared remote control

Features

4K Ultra HD Image Quality

The 1/1.8-inch Sony CMOS sensor captures detailed 3840 x 2160 video at up to 60fps, supporting professional broadcasting, presentations and live events.

Powerful 31x Optical Zoom

The 31x optical zoom lens offers a focal range of 6.91–214.64mm, capturing wide scenes and detailed close-ups from a distance without relying on digital enlargement.

AI-Powered Subject Tracking

Integrated AI algorithms support automatic subject tracking, intelligent framing and face-assisted focusing for lectures, presentations and live performances.

Quiet Motorised PTZ

Precision motors provide smooth horizontal and vertical camera movement. Remote positioning enables flexible camera control during recordings and live productions.

Advanced Image Processing

Intelligent autofocus, 3D noise reduction and adjustable image settings help deliver stable, detailed video in varying indoor lighting conditions.

Professional Video Outputs

HDMI, SDI and USB connectivity support integration with compatible video switchers, recorders, computers and broadcasting equipment. Available SDI and USB specifications depend on the ordered configuration.

IP Streaming and Compression

H.264 and H.265 compression, together with RTSP, RTMP and SRT protocols, support network broadcasting and streaming applications.

Flexible Remote Control

RS-232, RS-422/485 and IP control support professional AV integration. VISCA and Pelco protocols enable compatible controllers to operate camera movement and presets.

Preset Camera Positions

Store up to 255 preset positions, with ten accessible through the remote control, for quick transitions between speakers, presentation areas and audience views.

Important Information:

• Model: UV470A2-31, 31x optical zoom.
• 4K at 60fps is supported on compatible video outputs.
• 12G-SDI, USB 3.0 and NDI|HX3 availability depends on configuration.
• PoE+ requires compatible network equipment.
• External microphones and streaming equipment are separate.
• Designed primarily for professional indoor use.
• Warranty depends on regional supplier terms.

Technical Specifications:

What's in the Box:

• 1 x Minrray UV470A2-31 PTZ Camera
• Power Adapter
• RS-232 Control Cable
• USB Connection Cable
• Infrared Remote Control
• User Manual and Warranty Documentation
