KSTAR 1000VA 1KVA Online UDC UPS UDC9101S

KSTAR 1000VA 1KVA Online UDC UPS UDC9101S

Features

• True double-conversion
• Digital control guarantees high reliability
• ECO mode operation for energy saving
• Output receptacle control for non - critical load shedding capability
• Emergency power off function (EPO)
• Generator compatible
• Communications: RS-232, USB, SNMP card (Optional), Relay card (Optional)
• Bypass can be used when UPS is off (Set in LCD)
• Cold Start

Input

• Normal Voltage: 208 / 220 / 230 / 240Vac (L+N+PE)
• Operating Voltage Range: 110 - 300Vac @ (0-60%) Load; 120-300Vac @ (60-70%) Load; 140 - 300Vac @ (70-80%) Load; 160 - 300Vac @ (80-100%) Load
• Operating Frequency Range: 50Hz: 45-55Hz, 60Hz: 55-65Hz Auto Sensing
• Power Factor: 0.85@25%Load; 0.95@50%Load; 0.97@75%Load; 0.99 @ Normal Voltage & 100%) Load

Output

• Output Voltage: 208/220/230/240Vac:230Vac (Default)
• Power Factor: 0.9
• Voltage Regulation: +- 1%
• Frequency: Synchronized Range: 45-55Hz +- 0.02Hz @ 50Hz, 55-65Hz +- 0.02Hz @ 60HZ
• Battery Mode & None Synchronized Range: (50/60 +- 0.02)Hz
• Crest Factor : 3:1

Note

• A UPS is not designed to provide continuous power, merely a window period that allows a computer or other user to finalise the work at hand and shut down.

What's in the box:

• GICOM 1000VA UPS: 1
• USB Cable: 1
• User Manual: 1
• Driver Disc: 1
