Kingston KSM56R46BD4-64HA Memory Module 64GB 1 x 64GB DDR5 5600MT/s

Kingston KSM56R46BD4-64HA Memory Module 64GB 1 x 64GB DDR5 5600MT/s

Kingston memory is designed, manufactured and rigorously tested to meet the exact specifications of each brand name system.

Kingston's KSM56R46BD4-64HA is a 8G x 80-bit (64GB) DDR5-5600 CL46 SDRAM (Synchronous DRAM), 2Rx4, ECC, memory module, based on forty 4G x 4-bit FBGA components. The SPD is programmed to JEDEC standard latency DDR5-5600 timing of 46-45-45 at 1.1V. Each 288-pin DIMM uses gold contact fingers.

Features:

• Power Supply: VDD = 1.1V Typical
• VDDQ = 1.1V Typical
• VPP = 1.8V Typical
• VDDSPD = 1.8V to 2.0V
• On-Die ECC
• x80 ECC (x40, 2 independent I/O sub channels)
• 32 internal banks
• Hard/Soft Post Package Repair
• Sideband access with I3C/I2C
• PCB: Height 1.23” (31.25mm)
• RoHS Compliant and Halogen-Free
• Lifetime Warranty

Technical Specifications:

Capacity: 64 GB

Memory Type: DDR5 RDIMM

Form Factor: 288-Pin

Speed: DDR5-5600 (PC5-44800)

CAS Latency: CL46

Timing: 46-45-45

Voltage: 1.10 V

ECC Support: Yes

Buffered / Registered: Registered

Rank: 2Rx4

Heat Spreader: No
