HPE MSA 2060 SFF 2x16Gb FC 4-port Controller Storage Array P89060-B25

HPE MSA 2060 SFF 2x16Gb FC 4‑port Controller Storage Array P89060-B25

Accelerate Applications Affordably

The HPE MSA 2060 Storage is capable of delivering up to 395,000 IOPS for affordable application acceleration for small to medium-sized businesses.

The HPE MSA 2060 Storage allows users to define and deploy hybrid or flash storage configurations from day one and grow as their needs change.

Features:

• Customer configurable HPE MSA 2060 storage array models and storage media options available through the HPE Smart Choice program.
• HPE Smart Choice MSA Gen6 storage array bundles with up to 240 TB of raw storage capacity included, supporting 16 Gb Fibre Channel, 10 GbE iSCSI, and 12 Gb SAS host connectivity.
• MSA Gen6 HDD and SSD media options supporting an increase in MSA 2060 raw capacity of up to a maximum of 7.37 PB.
• All MSA Gen6 and Gen7 storage array models are now fully certified for use with HPE Morpheus VM Essentials Software.

HPE MSA’s "Set It and Forget It" Data Services Do Not Require a Dedicated Storage Administrator

The HPE MSA 2060 Storage is easy to install, easy to use, and easy to maintain, even for an IT generalist. Administrators will find the MSA 2060’s new Storage Management Utility intuitive and easy to navigate.

HPE MSA’s automated tiering engine dynamically responds to workload changes so you don’t have to, ensuring the hottest data will be moved to the fastest media automatically and in real time.

Leverage Data Protection Features to Keep Your Business Running in the Event of a Disaster

The HPE MSA 2060 Storage delivers virtualized snapshot technology, making data protection and instant recovery a snap.

Remote replication via Fibre Channel (FC) or iSCSI facilitates an affordable disaster recovery solution.

Encrypted SSDs and HDDs with local key management can be deployed to deliver a secure, encrypted hybrid flash array.

Flexible, Modular Architecture That Facilitates Growth into the Future

The HPE MSA 2060 Storage solution supports a mixture of 3.5-inch LFF and 2.5-inch SFF expansion enclosures for a maximum of nine enclosures (10 total including the array).

Start small and scale as needed with any combination of SSDs, Enterprise SAS HDDs, or Midline SAS HDDs.

Technical Specifications:

Storage
Drive Description: Up To 24 SFF HDD And/Or SSD Per Array Base Model
Capacity: Up To 7.37 PB (All SFF) Depending On Model And Drive Mix, With Full Expansion
Drive Form Factor: SFF
Included Drives: None
SED Drives Supported: Yes

Expansion
Storage Expansion Options:

• 24 Drive Bay 2060 SFF Drive Enclosure
• 12 Drive Bay 2060 LFF Drive Enclosure
• Supports Up To 9 Expansion Enclosures In Any Combination

Controller
Storage Controller:

• 2x 16 Gb Fibre Channel Controllers
• 4 Ports Each (8 Ports Total)

Connectivity
Host Connectivity: 16 Gb Fibre Channel

Compatibility
Compatible Operating Systems:

• Windows Server 2022
• Windows Server 2019
• Windows Server 2016
• VMware Vsphere 6.7
• Red Hat Linux 8
• SUSE SLES 15
• See HPE SPOCK For More Details

Form Factor And Design
Form Factor: 2U Rack Mount (Base Array Model)
Energy Efficiency: Energy Star Compliant

Physical Characteristics
Weight: 5 Kg (11 Lb)
Dimensions: 8.9 X 44.5 X 50.8 Cm (H X W X D)

Included Components
Included Transceivers: Not Included

Warranty
Warranty: Three-Year Limited Warranty, Parts Exchange Next Business Day Delivery On All Base Arrays And Drive Enclosures. MSA Drives And Other Options Carry A Separate Warranty.
