HPE MSA 1060 SFF 2x12Gb SAS 2-port Controller Storage Array P89130-B25

HPE MSA 1060 SFF 2x12Gb SAS 2‑port Controller Storage Array P89130-B25

Accelerate Applications Affordably

The HPE MSA 1060 Storage is capable of delivering over 154,000 IOPS for affordable application acceleration for small to medium-sized businesses and deployments.

The MSA 1060 platform delivers allows users to define and deploy hybrid or flash configurations from day one and grow as needs change.

Features:

• Customer configurable HPE MSA 1060 storage array models and storage media options available through the HPE Smart Choice program.
• MSA Gen6 HDD and SSD media options supporting an increase in MSA 1060 raw capacity of up to a maximum of 2.95 PB.
• All MSA Gen6 and Gen7 storage array models are now fully certified for use with HPE Morpheus VM Essentials Software.

MSA’s "Set and Forget" Data Services Do Not Require a Dedicated Storage Administrator to Manage

The HPE MSA 1060 Storage is easy to install, easy to use, and easy to maintain, even for an IT generalist. Administrators will find the MSA 1060’s new Storage Management Utility intuitive and easy to navigate.

HPE MSA’s automated tiering engine dynamically responds to workload changes so you don’t have to, ensuring the hottest data will be moved to the fastest media automatically and in real-time.

Leverage Data Protection Features to Keep your Business Running in the Event of a Disaster

The HPE MSA 1060 Storage delivers virtualized snapshot technology making data protection and instant recovery a snap.

Remote replication via Fibre Channel (FC) or iSCSI facilitates an affordable disaster recovery solution.

Flexible, Modular Architecture that Facilitates Growth into the Future

The HPE MSA 1060 Storage solution supports a mixture of 3.5-inch LFF and 2.5-inch SFF 2060 expansion enclosures for a maximum of three enclosures (four total including the array).

Start small and scale as needed with any combination of SSDs, Enterprise SAS HDDs, or Midline SAS HDDs.

Technical Specifications:

Storage
Drive Description: Up To 24 SFF HDD And/Or SSD On All 1060 Array Models
Capacity:

• Up To 737 TB (Base Array)
• Up To 2.95 PB With Maximum Expansion
  Drive Form Factor: SFF
  Included Drives: None
  SED Drives Supported: Yes

Expansion
Storage Expansion Options:

• 24-Drive Bay SFF 2060 Drive Enclosure
• 12-Drive Bay LFF 2060 Drive Enclosure
• Supports Up To 3 Expansion Enclosures

Controller
Storage Controller:

• 2x 12 Gb SAS Controllers
• 2 Ports Each

Connectivity
Host Connectivity: 12 Gb SAS

Compatibility
Compatible Operating Systems:

• Windows Server 2022
• Windows Server 2019
• Windows Server 2016
• VMware Vsphere 6.7
• Red Hat Linux 8
• SUSE SLES 15
• See HPE SPOCK For More Details

Form Factor And Design
Form Factor: 2U Rack Mount
Energy Efficiency: Energy Star Compliant

Physical Specifications
Weight: 5 Kg (11 Lb)
Dimensions: 8.9 X 44.5 X 50.8 Cm

Included Components
Included Transceivers: Not Required

Warranty
Warranty: Three-Year Limited Warranty, Parts Exchange Next Business Day Delivery On All Base Arrays And Drive Enclosures. MSA Drives And Other Options Carry A Separate Warranty.
