Hikvision 8-Port Gigabit Smart PoE Switch DS-3E1510P-SI-8P2F

Hikvision 8-Port Gigabit Smart PoE Switch DS-3E1510P-SI-8P2F

The Hikvision DS-3E1510P-SI-8P2F is an 8-Port Gigabit Smart PoE Switch designed for professional IP surveillance and network deployments. It provides eight Gigabit PoE RJ45 ports for simultaneously carrying network data and power to compatible devices, together with two Gigabit SFP fibre ports for flexible uplink connectivity. A total PoE power budget of 110W, IEEE 802.3af/at support and long-range PoE transmission of up to 300 metres make it particularly well suited to IP camera installations, while VLAN, QoS, STP/RSTP/ERPS, PoE Watchdog, cable detection and remote management capabilities provide the tools required to build and maintain a reliable surveillance network.

Key Features

• 8 × Gigabit PoE ports: Provides 10/100/1000 Mbps Ethernet connectivity with PoE for compatible IP cameras and other powered devices.
• 2 × Gigabit SFP ports: Enables fibre-optic uplinks for extending and integrating the switch into larger network infrastructures.
• 110W PoE power budget: Supplies up to 30W per compatible PoE port under IEEE 802.3af/at standards.
• Up to 300m long-range PoE: Extended transmission mode allows compatible surveillance devices to be deployed beyond conventional Ethernet distances.
• 20Gbps switching capacity: Provides sufficient switching bandwidth for multiple Gigabit surveillance connections.
• Smart network management: Supports IEEE 802.1Q VLAN, QoS, SNMP, DHCP snooping and ARP anti-spoofing.
• Loop prevention: STP, RSTP and ERPS support helps maintain network availability and prevent switching loops.
• PoE Watchdog: Helps detect and restart unresponsive connected cameras to improve surveillance-system availability.
• Cable detection: Assists installers and administrators with identifying network cable faults.
• 6kV surge protection: Provides additional electrical protection for demanding surveillance deployments.

8-Port Gigabit PoE Connectivity

The DS-3E1510P-SI-8P2F provides eight 10/100/1000 Mbps RJ45 PoE ports, allowing compatible network cameras and other powered devices to receive both data and electrical power through a single Ethernet cable. IEEE 802.3af and IEEE 802.3at compatibility provides up to 30W of power per supported port, subject to the switch's total 110W PoE power budget.

Dual Gigabit SFP Uplinks

Two 100/1000 Mbps SFP ports provide flexible fibre-optic connectivity for network uplinks. These interfaces are useful when connecting the switch across longer distances or integrating surveillance equipment into a larger fibre-based network infrastructure.

Up to 300m Long-Range PoE

Long-range transmission mode allows PoE connections on ports 1 through 8 to reach distances of up to 300 metres under supported operating conditions. This provides additional installation flexibility for surveillance cameras positioned farther away from the network equipment than conventional Ethernet installations normally allow.

Smart Network Management

The switch provides Layer 2 management capabilities including IEEE 802.1Q VLAN tagging, QoS, SNMP, DHCP snooping, ARP anti-spoofing and storm control. STP, RSTP and ERPS loop-prevention technologies help maintain network stability, while management through supported Hikvision platforms provides convenient monitoring and maintenance of surveillance network infrastructure.

PoE Watchdog and Cable Detection

PoE Watchdog functionality can detect supported connected cameras that have stopped responding and automatically restart the relevant PoE connection. Integrated cable detection assists with identifying cabling faults, simplifying troubleshooting during network installation and ongoing maintenance.

Technical Specifications

What’s in the Box:

• 1 × Hikvision DS-3E1510P-SI-8P2F 8-Port Gigabit Smart PoE Switch
• 1 × Power Adapter

Build a reliable and manageable IP surveillance network with eight Gigabit PoE ports, dual Gigabit SFP uplinks, a 110W PoE budget, up to 300m long-range transmission and comprehensive Layer 2 management using the Hikvision DS-3E1510P-SI-8P2F.
