Hikvision 4MP Smart Hybrid Light with ColorVu Motorized Varifocal Bullet Network Camera DS-2CD2647G3-LIZSY(2.8-12MM)

Hikvision 4MP Smart Hybrid Light with ColorVu Motorized Varifocal Bullet Network Camera DS-2CD2647G3-LIZSY(2.8-12MM)

The DS-2CD2647G3-LIZSY (2.8–12 mm) is a versatile AI-powered IP turret camera designed for professional surveillance. It features a motorized varifocal lens that allows flexible adjustment between wide-angle and telephoto views, making it suitable for monitoring both large areas and distant subjects. Equipped with advanced IR and white-light illumination, the camera ensures clear day and night visibility.

Features:

• HikAI-ISP for excellent noise reduction effect
• 24/7 colorful imaging via ColorVu technology
• Scene-adaptive WDR
• Focus on Person and Vehicle classification based on deep learning
• Motorized varifocal lens for easy installation and monitoring
• Anti-corrosion design, providing reliability and longevity compared to standard (NEMA4X)
• Smart Hybrid Light: Integrates IR and White lights, 3 supplemental lighting modes
• Water and dust resistant (IP67) and vandal resistant (IK10)

Its AI capabilities include facial recognition, perimeter protection, and smart analytics such as line crossing and intrusion detection. The camera supports high-resolution video capture with multiple streaming options, enabling detailed monitoring and efficient bandwidth management. Built for reliability, it offers weatherproof and vandal-resistant construction, making it suitable for both indoor and outdoor deployments in challenging environments.

The camera integrates smoothly with network systems, providing remote access, storage flexibility, and smart event notifications, ensuring comprehensive and intelligent surveillance coverage.

Technical Specifications:

Camera Overview

Image Sensor: 1/1.8" Progressive Scan CMOS

Max. Resolution: 2688 × 1520

Min. Illumination: Color 0.0005 Lux (F1.2, AGC ON), 0 Lux with light

Shutter Time: 1 s to 1/100,000 s

Day & Night: IR cut filter

Angle Adjustment: Pan 0°–355°, Tilt 0°–90°, Rotate 0°–360°

Lens

Type: Motorized varifocal lens, 2.8–12 mm

FOV: Horizontal 114.6°–41.8°, Vertical 59.3°–23.6°, Diagonal 141.3°–48.1°

Mount: Integrated

Aperture: F1.2, Fixed Iris

Depth of Field: 1 m to ∞

DORI

Wide: D 61.5 m, O 24.4 m, R 12.3 m, I 6.2 m

Tele: D 151.7 m, O 60.2 m, R 30.3 m, I 15.1 m

Illuminator

Type: White Light, IR

Range: Up to 60 m

Smart Supplement Light: Yes

IR Wavelength: 850 nm

Video

Main Stream: 50 Hz: 25 fps (2688×1520, 1920×1080, 1280×720), 60 Hz: 30 fps

Sub-Stream: 50 Hz: 25 fps (1280×720, 640×480, 640×360), 60 Hz: 30 fps

Third Stream: 10 fps (supported under certain settings)

Compression: H.265/H.264/H.264+/H.265+ (Main), H.265/H.264/MJPEG (Sub), H.265/H.264 (Third)

Bit Rate: 32 Kbps–8 Mbps

Bit Rate Control: CBR, VBR

ROI: 1 fixed region for main stream

SVC: Supported (H.264/H.265)

Audio

Type: Mono

Compression: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC

Bit Rate: 16–320 Kbps

Sampling Rate: 8/16/32/48 kHz

Noise Filtering: Yes

Network & Protocols

Protocols: TCP/IP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP/RTSP, NTP, SMTP, IGMP, 802.1X, QoS, IPv4/IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket

Simultaneous Live View: Up to 6 channels

API: ONVIF Profile S/T/G, ISAPI, SDK, ISUP

Users: Up to 32, 3 levels (admin, operator, user)

Security: Password protection, HTTPS, 802.1X, watermark, IP filter, authentication, TLS 1.1/1.2/1.3, MAC host authentication

Storage & Interface

Network Storage: NAS (NFS, SMB/CIFS), ANR

On-Board Storage: microSD/microSDHC/microSDXC up to 512 GB

Ethernet: 1 RJ45 10/100 Mbps

Audio: 1 input, 1 output (non-equilibrium)

Alarm: 1 input, 1 output (max. 24 VDC/AC, 1 A)

Reset Key: Yes

Events & Smart Functions

Basic Event: Motion detection, video tampering, exception

Smart Event: Scene change detection

Linkage: Upload to FTP/NAS/memory card, trigger recording/capture, send email

Deep Learning: Face capture, perimeter protection (line crossing, intrusion, region entrance/exit)

General

Power: 12 VDC ±25%, 1.08 A (max 13 W), PoE IEEE 802.3at Class 4 (max 15 W)

Material: Metal (front cover, body, bracket)

Dimensions: Ø140 mm × 333.8 mm

Weight: 1540 g; Package 2311 g

Storage Conditions: -30 °C to 60 °C, ≤95% humidity

Operating Conditions: -30 °C to 60 °C, ≤95% humidity

Functions: Heartbeat, mirror, flash log, password reset via email, pixel counter, anti-banding

Languages: 33 languages including English, Russian, Chinese, Spanish, French, Korean, Japanese, etc.

Approvals & Protection

EMC: CE-EMC, EN 55032, EN 50130-4, EN IEC 61000-3-2/3

Safety: UL 62368-1, CB IEC 62368-1, CE-LVD EN 62368-1

Environment: CE-RoHS 2011/65/EU

Protection: IP67, IK10, NEMA 4X
