Hikvision 4MP 8-32mm DeepinView PTRZ Moto Varifocal Dome Camera IDS-2CD7546G2-XZHSY(8-32MM)

Hikvision 4MP 8-32mm DeepinView PTRZ Moto Varifocal Dome Camera IDS-2CD7546G2-XZHSY(8-32MM)

The Hikvision iDS-2CD7546G2-XZHSY(8-32mm) is a professional 4MP DeepinView PTRZ motorized varifocal dome network camera designed for intelligent surveillance in demanding indoor and outdoor environments. Combining an 8–32mm motorized varifocal lens with DarkFighter 2.0 low-light technology, 150dB AWDR and high-frame-rate recording, it provides detailed imaging across challenging lighting and movement conditions. PTRZ remote adjustment simplifies installation, while IP67, IK10 and NEMA 4X protection provide enhanced durability for demanding deployments.

Key Features

• 4MP high-quality imaging: Provides detailed surveillance imaging using a large 1/1.8-inch image sensor.
• 8–32mm motorized varifocal lens: Provides adjustable viewing coverage for medium- to longer-range surveillance applications.
• PTRZ remote adjustment: Pan, tilt, rotate and zoom capability simplifies camera positioning and configuration during installation.
• DarkFighter 2.0: Advanced low-light imaging technology provides improved visibility in extremely low illumination.
• 150dB AWDR: Helps preserve detail in scenes containing strong backlighting and extreme differences between bright and dark areas.
• High-frame-rate imaging: Supports up to 4MP at 60fps and 2MP at 120fps for clearer capture of fast-moving subjects.
• ShotN technology: Designed to capture humans and vehicles travelling at different speeds more clearly.
• IP67, IK10 and NEMA 4X: Provides weather, vandal and moderate anti-corrosion protection for demanding installations.

4MP DeepinView Imaging

The iDS-2CD7546G2-XZHSY uses a 1/1.8-inch image sensor to provide high-quality 4MP surveillance imaging. High-frame-rate capability reaches up to 60fps at 4MP and up to 120fps at 2MP, helping capture greater detail when monitoring rapidly moving people, vehicles and other subjects.

8–32mm Motorized Varifocal Lens with PTRZ

This specific configuration incorporates an 8–32mm motorized varifocal lens for adjustable surveillance coverage. Hikvision's PTRZ design provides remote pan, tilt, rotate and zoom adjustment, allowing installers to configure the camera's viewing direction and framing more efficiently without repeatedly making physical adjustments at the camera.

DarkFighter 2.0 Low-Light Performance

DarkFighter 2.0 technology is designed to provide detailed surveillance imaging in extremely low-light environments. Minimum illumination reaches 0.0005 lux in colour and 0.0001 lux in black and white, while integrated infrared illumination enables imaging at 0 lux.

150dB Advanced Wide Dynamic Range

150dB AWDR technology helps maintain usable detail when strongly illuminated and shadowed areas appear within the same scene. This makes the camera suitable for entrances, transport environments and other locations where lighting conditions can vary dramatically across the monitored area.

High-Speed Capture with ShotN

ShotN technology is designed to capture humans and vehicles moving at different speeds more clearly. Combined with frame rates of up to 4MP at 60fps and 2MP at 120fps, the camera is well suited to surveillance environments where capturing fast-moving subjects is important.

Technical Specifications

What’s in the Box:

• 1 × Hikvision iDS-2CD7546G2-XZHSY(8-32mm) 4MP DeepinView PTRZ Motorized Varifocal Dome Network Camera

Deploy advanced professional surveillance with 4MP DeepinView imaging, an 8–32mm motorized varifocal lens, PTRZ remote adjustment, DarkFighter 2.0 low-light performance, 150dB AWDR, high-frame-rate recording and rugged IP67, IK10 and NEMA 4X protection using the Hikvision iDS-2CD7546G2-XZHSY(8-32mm).
