Hikvision 4MP 2.8mm Panoramic AcuSense Fixed Network Turret Camera DS-2CD2346G2P-ISU/SL(2.8mm)

Hikvision 4MP 2.8mm Panoramic AcuSense Fixed Network Turret Camera DS-2CD2346G2P-ISU/SL(2.8mm)

The Hikvision DS-2CD2346G2P-ISU/SL(2.8mm) is a 4MP Panoramic AcuSense Fixed Turret Network Camera designed to capture an ultra-wide 180° scene in a single panoramic image. Two 1/2.5-inch Progressive Scan CMOS sensors and dual 2.8mm lenses combine to deliver a stitched 3040 × 1368 image with a 180° horizontal field of view. Powered-by-DarkFighter low-light technology, up to 30m infrared illumination, 120dB True WDR and AcuSense human and vehicle classification provide dependable surveillance around the clock, while built-in two-way audio and active strobe-light and audio alarms provide additional real-time deterrence capabilities.

Key Features

• 4MP panoramic imaging: Dual 1/2.5-inch Progressive Scan CMOS sensors produce a single panoramic image at up to 3040 × 1368 resolution.
• 180° panoramic coverage: Dual 2.8mm fixed lenses provide an ultra-wide 180° horizontal and 81° vertical field of view.
• Powered by DarkFighter: Enhanced low-light technology provides colour imaging at illumination levels down to 0.003 lux.
• Up to 30m infrared: Integrated 850nm IR illumination enables surveillance in complete darkness.
• 120dB True WDR: Helps preserve image detail in scenes containing strong backlighting and high-contrast areas.
• AcuSense intelligence: Deep-learning algorithms provide human and vehicle target classification for improved alarm accuracy.
• Active deterrence: Integrated strobe light and audio alarm can provide an immediate warning to potential intruders.
• Built-in two-way audio: Integrated microphone and speaker enable real-time listening and communication.
• IP67 protection: Metal construction provides water and dust resistance for indoor and outdoor surveillance installations.

180° Panoramic Surveillance

The DS-2CD2346G2P-ISU/SL combines two 1/2.5-inch Progressive Scan CMOS sensors and dual 2.8mm lenses to produce one panoramic image covering the entire scene. Its 180° horizontal and 81° vertical field of view can significantly reduce blind spots and makes the camera particularly useful for entrances, building perimeters, courtyards, warehouses and other broad monitoring areas.

4MP Dual-Sensor Imaging

The dual imaging system generates a maximum stitched resolution of 3040 × 1368. The main stream operates at up to 25fps at full resolution in 50Hz mode or 24fps in 60Hz mode, providing detailed panoramic video without requiring separate camera feeds for each sensor.

Powered-by-DarkFighter with 30m IR

Powered-by-DarkFighter technology provides enhanced low-light imaging with minimum colour illumination of 0.003 lux at F1.6 with AGC enabled. When ambient light is insufficient, integrated 850nm infrared illumination provides visibility at 0 lux over distances of up to 30 metres.

AcuSense Human and Vehicle Classification

Hikvision AcuSense technology uses deep-learning algorithms to distinguish human and vehicle targets during supported security events. This allows the system to focus on relevant targets and helps reduce unnecessary alarms caused by other movement within the monitored scene.

Active Strobe and Audio Deterrence

In addition to intelligent detection, the DS-2CD2346G2P-ISU/SL incorporates an active strobe light and audio alarm that can be used to warn potential intruders. A built-in microphone and speaker also provide two-way audio functionality for real-time security communication.

Technical Specifications

*MJPEG is available on the sub-stream.

What’s in the Box:

• 1 × Hikvision DS-2CD2346G2P-ISU/SL(2.8mm) 4MP Panoramic AcuSense Fixed Turret Network Camera

Cover an ultra-wide scene with a single camera using the Hikvision DS-2CD2346G2P-ISU/SL(2.8mm), combining dual-sensor 4MP panoramic imaging, a 180° horizontal field of view, Powered-by-DarkFighter low-light performance, 30m infrared illumination, AcuSense human and vehicle classification, two-way audio and active strobe and audio deterrence.
