Hikvision 16-channel FHD 1080P Lite 1U H.265 DVR DS-7216HGHI-M1/T

Hikvision 16-channel FHD 1080P Lite 1U H.265 DVR DS-7216HGHI-M1/T

Features:

• Deep learning based human and vehicle targets classification of Motion Detection 2.0
• H.265 Pro+/H.265 Pro/H.265 video compression
• HDTVI/AHD/CVI/CVBS/IP video input
• Audio via coaxial cable
• Up to 18-ch IP camera inputs (up to 5 MP)
• Up to 1080p Lite@15 fps encoding capability
• Support all channels HDTVI two-way audio technology

Technical Specifications:

Video & Audio

IP Video Input: 2-ch (expandable up to 18-ch)

• Supports up to 5 MP resolution
• Compatible with H.265+/H.265/H.264+/H.264 IP cameras

Analog Video Input: 16-ch

• BNC interface (1.0 Vp-p, 75 Ω), supports coaxitron connection

HDTVI Input: 1080p25, 1080p30, 720p25, 720p30
AHD Input: 1080p25, 1080p30, 720p25, 720p30
HDCVI Input: 1080p25, 1080p30, 720p25, 720p30
CVBS Input: PAL/NTSC

HDMI Output: 1-ch, resolutions: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
VGA Output: 1-ch, resolutions: 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz

Audio Input: 1-ch, RCA (2.0 Vp-p, 1 KΩ)
Audio Output: 1-ch, RCA (Linear, 1 KΩ)
Two-Way Audio: 1-ch, RCA (2.0 Vp-p, 1 KΩ) using first audio input

Synchronous Playback: 16-ch

Recording

Video Compression: H.265 Pro+/H.265 Pro/H.265/H.264+/H.264
Encoding Resolution: 1080p lite / 720p / VGA / WD1 / 4CIF / CIF

Frame Rate:

Main Stream:

• 1080p stream: 1080p lite / 720p lite / WD1 / 4CIF / VGA @ 15 fps; CIF @ 25 fps (PAL) / 30 fps (NTSC)
• 720p stream: 720p / WD1 / 4CIF / VGA @ 15 fps; CIF @ 25 fps (PAL) / 30 fps (NTSC)
• Standard definition: WD1 / 4CIF / VGA / CIF @ 25 fps (PAL) / 30 fps (NTSC)

Sub-Stream:

• 1080p & 720p: CIF / QVGA @ 15 fps
• Standard definition: CIF / QVGA @ 25 fps (PAL) / 30 fps (NTSC)

Video Bitrate: 32 Kbps – 4 Mbps
Dual-Stream: Supported
Stream Type: Video, Video & Audio

Audio Compression: G.711u
Audio Bitrate: 64 Kbps

Network

Remote Connection: Up to 128 connections
Network Protocols: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, UPnP™, HTTPS, ONVIF
Network Interface: 1 × RJ45 10/100M self-adaptive Ethernet

Auxiliary Interface

SATA: 1 interface, supports up to 6 TB per disk
USB Interface: Rear panel: 2 × USB 2.0

General

Power Supply: 12 VDC, 2 A
Power Consumption: ≤ 18 W
Working Temperature: -10 °C to 55 °C (14 °F to 131 °F)
Working Humidity: 10%–90%
Dimension (W × D × H): 263 × 220 × 48 mm (10.3 × 8.7 × 1.9 in)
Weight: ≤ 2.2 kg (4.9 lb)
