Grandstream Networks GWN7665 Tri-Band Wi-Fi 6E Indoor Access Point

Grandstream Networks GWN7665 Tri-Band Wi-Fi 6E Indoor Access Point

GWN 802.11ax Tri-Band Wi-Fi 6E Access Point

The GWN7665 is a powerful, enterprise-grade Wi-Fi 6E access point, ideal for small-to-medium sized businesses, multiple floor buildings, residential settings and commercial locations. It offers tri-band 2x2:2 MU-MIMO with DL/UL OFDMA technology and a sophisticated internal antenna design for stronger anti-interference, more stable connection, maximum network throughput and expanded Wi-Fi coverage range. The GWN7665 is supported by GWN. Cloud and GWN Manager, Grandstream’s cloud and on-premise Wi-Fi management platform that and makes managing your network or several networks across multiple locations easier than ever before. It also uses a controller-less network management architecture in which the controller is embedded within the product’s web user interface for easy administration of locally deployed Wi-Fi APs. The GWN7665 is the ideal Wi-Fi AP for voice-over-Wi-Fi deployments and offers a seamless connection with Grandstream’s Wi-Fi capable IP phones. With support for advanced QoS, low-latency real-time applications, mesh networks, captive portals, Bluetooth® Low Energy (BLE) 5.2, 384 concurrent clients and dual Gigabit network ports with PoE/PoE+, the GWN7665 is an ideal Wi-Fi access point for business-grade wireless network deployments with medium-to-high user density.

Features

• 5.4Gbps aggregate wireless throughput, 3.5 Gigabit wireline ports
• Tri-Band 2x2:2 MU-MIMO with DL/UL OFDMA technology
• Up to 175-meter coverage range
• Support 384 concurrent Wi-Fi client devices
• Built-in Bluetooth BLE 5.2
• Advanced QoS to ensure real-time performance of low-latency applications
• Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
• Self-power adaptation upon auto-detection of PoE or PoE+
• Embedded controller manages up to 50 local GWN APs; GDMS Networking offers unlimited AP management, & GWN Manager offers on-premise software AP management

Technical Specification

Product: Grandstream Networks GWN7665 Tri-Band Wi-Fi 6E Indoor Access Point

Wi-Fi Standards: Tri-Band IEEE 802.11 a/b/g/n/ac/ax

Wi-Fi Data Rates: 2.4G, 5G, 6G

Antennas

• 7 individual internal antennas
• 2.4GHz x 2, gain 4.0dBi
• 5 GHz x 2, gain 5.0dBi
• 6 GHz x 2, gain 4.5dBi
• BT, gain 4.0dBi

MU-MIMO

• 2×2:2 2.4GHz
• 2×2:2 5GHz
• 2×2:2 6GHz

Bluetooth: BLE 5.2

Network Interfaces

• 1x autosensing 10/100/1000 Base-T Ethernet Port
• 1x autosensing 10/100/2500 Base-T Ethernet Port

Mounting: Indoor wall mount or ceiling mount, kits included

Power: PoE 802.3at
