Description
Description
Grandstream L3 Aggregation Fibre Switch GWN7832
The Grandstream GWN7832 is a high-performance Layer 3 aggregation network switch designed for medium-to-large businesses and enterprise networks. Equipped with 12 × 10Gbps SFP+ ports and up to 240Gbps switching capacity, it provides the high-speed fibre connectivity required for aggregation, backbone and core network applications. Advanced Layer 3 routing, VLAN, QoS, multicast, security and centralised management capabilities provide comprehensive control over demanding network deployments.
Key Features
- 12 × 10Gbps SFP+ ports for high-speed fibre and aggregation connectivity.
- 240Gbps switching capacity with 120Gbps total non-blocking throughput.
- Layer 3 routing with static routing, RIP, RIPng, OSPF and OSPFv3 support.
- Advanced VLAN, QoS, link aggregation and IGMP/MLD Snooping capabilities.
- Enterprise security features include 802.1X, RADIUS, TACACS+, ARP Inspection, IP Source Guard and DHCP Snooping.
- Manage locally through the Web UI or CLI, or centrally through Grandstream network management platforms.
- Supports an optional redundant power supply for improved power resilience.
Technical Specifications
| Specification | Details |
|---|---|
| Brand | Grandstream |
| Model | GWN7832 |
| Product Type | Layer 3 Aggregation Managed Network Switch |
| 10 Gigabit SFP+ Ports | 12 × 10Gbps SFP+ |
| Console Port | 1 |
| Forwarding Mode | Store-and-Forward |
| Total Non-Blocking Throughput | 120Gbps |
| Switching Capacity | 240Gbps |
| Packet Buffer | 16MB |
| MAC Address Table | Up to 32K MAC Addresses |
| VLAN Support | Up to 4K VLANs |
| VLAN Features | Port-Based VLAN / IEEE 802.1Q VLAN Tagging / Voice VLAN |
| Spanning Tree | STP / RSTP / MSTP |
| Link Aggregation | Supported |
| Layer 3 Routing | Static & Dynamic Routing |
| Dynamic Routing Protocols | RIP / RIPng / OSPF / OSPFv3 |
| IPv4 / IPv6 | Supported |
| Multicast | IGMP Snooping / MLD Snooping |
| DHCP Features | DHCP Server / DHCP Relay / Option 82 / Option 60 / Option 160 / Option 43 |
| QoS | Port Priority / Priority Mapping / Traffic Shaping / Rate Limiting |
| Queue Scheduling | SP / WRR / WFQ / SP-WRR / SP-WFQ |
| Access Control Lists | Ethernet / IPv4 / IPv6 ACL |
| Authentication | 802.1X / MAC Authentication / RADIUS / TACACS+ |
| Security Features | Port Security / Storm Control / IP & IPv6 Source Guard / DoS Protection / ARP Inspection / DHCP & DHCPv6 Snooping |
| Loop Protection | BPDU Protection / Root Protection / Loopback Protection |
| Management | Local Web UI / CLI / GDMS Networking / GWN Manager |
| Management Protocols & Tools | SNMP / RMON / LLDP / LLDP-MED / Syslog / Ping / Traceroute / Port Mirroring |
| Power Supply | Integrated Power Supply |
| AC Input | 100–240V AC, 50–60Hz |
| Redundant Power Supply | Optional External RPS Supported |
| Compatible Optional RPS | Grandstream RPS-60W-B |
| Cooling | 2 × Fans |
| Operating Temperature | 0°C to 45°C |
| Storage Temperature | -10°C to 60°C |
| Operating Humidity | 10%–90% RH, Non-Condensing |
Build a high-capacity enterprise aggregation layer with 12-port 10GbE connectivity, advanced Layer 3 routing and flexible centralised management using the Grandstream GWN7832.
