Epson LQ-690IIN 487 cps 24-pin A4 Dot Matrix Printer C11CJ82403

Epson LQ-690IIN 487 cps 24-pin A4 Dot Matrix Printer C11CJ82403

Fast and reliable dot matrix printing with the Epson LQ-690II. Its robust nature and modern design fit comfortably into any environment.

Designed with productivity in mind, the LQ-690II is an ultra-reliable dot matrix printer that offers an impressive ribbon yield. It is fast and compact with a robust build. Its modern design allows effortless integration into any work environment, be it an office or a warehouse.

Fast printing

Print faster and more productively. The LQ-690II prints the original + six copies, and is capable of printing an impressive 487 cps (10 cpi) when using printer resident fonts.

High ribbon yield

In a demanding and fast-moving work environment a high ribbon yield is essential, and with 10 million characters per ribbon, this marks the LQ-690II as a leading force in the flatbed market. It is also cost-effective, with long ribbon replacement cycles, low running costs and total cost of ownership. In addition, the ribbon is transferrable, which means that you can use ribbons from your current printer in the new printer, resulting in less cost and waste.

Dependable

Durable and built to last, users will be assured by the MTBF (mean time between failures) of 20,000 power on hours. The robust casing can stand up to high humid and heat conditions, which makes the LQ-690II ideal for any work environment. This results in greater productivity and less maintenance from down time - essential when producing large amounts of documents and data.

Smart design

This compact hard-working printer is designed to fit on your desk. With its modern, black and white casing, it blends in seamlessly in both office and warehouse environments.

Specifications:

Printing

Maximum resolution: 360 x 180 DPI

Maximum printing width (columns): 106

Colour: No

Maximum print speed: 487 cps

Maximum print speed (draft): 366 cps

Maximum print speed (LQ): 121 cps

Maximum number of copies: 7 copies

Built-in barcodes: CODABAR (NW-7), Code 39, Code-128 Codabar Library, EAN128, EAN13, Industrial 2/5, Interleaved 2/5, Matrix 2/5, POSTNET, UPC-A, UPC-E

Character sets: ISO 8859-15, Italic, PC437, PC708, PC720, PC850, PC858, PC864, PCAR864, Roman 8

Paper handling

Paper feed: Manual, Pull tractor

Paper tray media types: Envelopes, Labels, Plain paper, Roll

Continuous paper thickness range: 0.065 - 0.49 mm

Label thickness range: 0.16 - 0.19 mm

Multi-part paper thickness range: 0.12 - 0.49 mm

Single sheet thickness range: 0.065 - 0.15 mm

Features

Product colour: Black, White

Buffer size: 128 KB

Sound pressure level (printing): 59 dB

Ports & interfaces

Standard interfaces: Parallel, USB 2.0

Endurance

Print head: 24-pin

Print head life: 400 million characters

Ribbon life: 10 million characters

Mean time between failures (MTBF): 20000 h

Power

Power consumption (typical): 38 W

Power consumption (standby): 3 W

Operational conditions

Operating temperature (T-T): 5 - 35 °C

System requirements

Windows operating systems supported: Yes

Bundled software: Epson Status Monitor
