DJI Zenmuse V1 Loudspeaker CP.EN.00000649.01

DJI Zenmuse V1 Loudspeaker CP.EN.00000649.01

DJI's First Speaker for Multi-Payload Drone Platforms - Reach Loud and Clear

Zenmuse V1 is DJI's first speaker designed for multi-payload drone platforms, compatible with Matrice 350 RTK and Matrice 300 RTK. It boasts high volume and long broadcast distance, and supports multiple broadcast modes, making it ideal for scenarios like public safety, emergency rescue, and more.

Features:

• Amplify your drone operations with the DJI Zenmuse V1 Speaker for clear audio broadcasts.
• Ensure safety with drone speaker's payload protection, preventing damage from overuse.
• Communicate effectively using text-to-speech on your Matrice 350 RTK or 300 RTK drone.
• Achieve optimal audio clarity with a max 127dB sound level from this powerful drone speaker.
• Control broadcasts remotely; set a button for easy start, stop, and loop playback features.
• Import MP3, AAC, & WAV files for custom audio with the Zenmuse V1, enhancing drone utility.

Multiple Broadcast Modes

Record & Broadcast

Record and transmit messages to the speaker using the DJI Pilot 2 app. This feature includes local playback and recording storage. Recording a broadcast is instant and convenient, enabling rapid communication of important information in emergent scenarios without complex operations.

Text-to-Speech

Input text can be converted to speech via the DJI Pilot 2 app and transmitted to the speaker. This mode supports adjustments to tone and speech rate, as well as loop playback, ensuring that information is conveyed clearly and flexibly to the target audience.

Audio File Playback

The DJI Pilot 2 app supports the import of local audio files, which can then be transmitted to the speaker for playback. This allows for the quick dissemination of preset content during operations, enhancing efficiency and smoothness.

Powerful Sound, Extended Reach

At 1 meter, Zenmuse V1's maximum loudness can reach 127 decibels, on par with the sound level of a jet taking off. Powerful volume ensures clear communication. With an effective broadcast distance of up to 500 meters, it ensures coverage even in vast areas.

Clear, Directional Recording

During recording, DJI RC Plus can directionally capture voices directly above the microphone. Combined with environmental noise cancelling technology, it effectively minimizes surrounding noise interference, ensuring clearer recordings.

Precise Control, Targeted Broadcast

Zenmuse V1 can synchronize with other gimbal-equipped payloads to achieve coordinated tilt angles, ensuring that the sound is directed precisely towards the intended direction, thereby enhancing the broadcast efficiency.

Reliable and Intuitive

Payload Protection

Zenmuse V1 is equipped with multiple protection mechanisms for temperature, overcurrent, power, and more, enhancing the product's reliability and lifespan.

Hearing Protection

When the drone is not in flight and the volume exceeds 40%, the DJI Pilot 2 app will display a pop-up reminder to prevent discomfort to people nearby.

Strong Environmental Adaptability

With an IP54 rating for dust and water resistance, Zenmuse V1 can operate in ambient temperatures ranging from -20 Degree to 50 Degree C (-4 Degree to 122 Degree F), making it adaptable to various operating environments.

Efficient Remote Controller Shortcut

Zenmuse S1 supports customizable shortcut of the remote controller for one-press recording. Press once to start recording, and press again to play the recording, providing convenient operation to significantly improve the efficiency of on-site personnel.

Flexible Mounting, Lightweight Build

Zenmuse V1 can be mounted to any gimbal connector of the single downward gimbal, dual downward gimbals, or the single upward gimbal, accommodating various operational needs. Weighing only 0.69 kg, it is compact and easy to carry.

Mobile SDK

With the help of the Mobile SDK, users can quickly integrate the functions of the Zenmuse V1 into their self-developed mobile apps, allowing drone applications to penetrate business scenarios and improve operational efficiency.

Technical Specifications:

Rated Power: 30 W
Supported Aircraft: Matrice 300 RTK (requires DJI RC Plus), Matrice 350 RTK
Shell Temperature: 122° F (<50° C, plastic shell)
Ingress Protection Rating: IP54

Operating Temperature: -4° to 122° F (-20° to 50° C)
Storage Temperature: -4° to 140° F (-20° to 60° C)

Gimbal
Stabilization System: Single-axis (tilt)
Angular Vibration Range: Hover ±0.01°, Flight ±0.02°
Mounting: Detachable DJI SKYPORT
Mechanical Range: Tilt -125° to +25°
Controllable Range: Tilt -120° to +20°
Operation Mode: Follow / Free / Re-center

Speaker
Impedance: 4 Ohm
Nominal Power: 25 W
Effective Broadcast Distance: 1,640.42' (500 m)
Max Sound Pressure Level: 127 dB @ 3.2' (1 m)
Effective Bandwidth: 800 Hz to 8 kHz

Basic Features
Record & Broadcast: Record and broadcast, local playback, and storage
Text-to-Speech: Supports English and Mandarin Chinese
Audio File Playback: Supports MP3, AAC, and WAV formats
Playback Control: Start/Stop recording, Loop playback, Volume adjustment
Remote Controller Button: One button can start recording and press again to stop/play
Gimbal Synchronization: Supports synchronized control with other gimbal-equipped payloads

Special Features
Directional Audio Recording: Supports directional audio pickup and environmental noise reduction
Payload Protection: Speaker temperature protection, overcurrent protection, and power protection

Dimensions (L x W x H): 5.27 × 4.68 × 5.51" (134 × 119 × 140 mm)
Weight: 24.33 oz (690 g) ±10 g
