DJI's First Spotlight for Multi-Payload Drone Platforms - Zenmuse S1 Light Up The Night

Zenmuse S1 is DJI's first spotlight designed for multi-payload drone platforms, compatible with Matrice 350 RTK and Matrice 300 RTK. Utilizing the LEP technology, it offers high brightness and long illumination distance, and supports multiple lighting modes. This makes it ideal for public safety, emergency rescue, inspection, and other nighttime operations.

Features:

• Enhance your DJI Matrice drone with this powerful Zenmuse S1 Spotlight for superior visibility.
• The Zenmuse S1's impressive illumination distance reaches up to 1640 ft, ideal for search & rescue.
• Operate in various lighting conditions with low beam, high beam, and both-on modes for your drone.
• This drone spotlight features synchronized gimbal control, ensuring light follows your camera's view.
• With an IP54 rating, the durable Zenmuse S1 Spotlight withstands tough weather during drone flights.
• Customize remote controller buttons for easy light on/off, brightness, and lighting mode adjustments.

Multiple Lighting Modes

Low Beam Mode

Provides a 15 Degree field of view (FOV) within a distance of 150 meters, covering the illumination range of a camera at 5x zoom or above. This mode is suitable for most short-distance search and inspection needs.

High Beam Mode

Utilizing the LEP (Laser Excited Phosphor) technology for enhanced light penetration, this mode offers a 4 Degree field of view (FOV) at a distance of 300 meters. It covers the illumination range of a camera at 15x zoom or above, enhancing efficiency in emergency rescue and public safety operations.

Both On Mode

Engages both low and high beams simultaneously, delivering greater central illuminance than the High Beam mode alone. It maintains the FOV of the Low Beam mode while extending the observation distance up to 500 meters. This mode offers maximum illumination coverage for comprehensive situational awareness.

Strobe Mode

Zenmuse S1 supports high-frequency strobing to effectively alert and draw attention from target individuals, making it particularly useful for signaling in emergency rescue and public safety scenarios.

Brightness Meets Energy Efficiency

Zenmuse S1 delivers a maximum central illuminance of 35 lux at 100 meters, providing ample lighting in dark environments to clearly distinguish details of the subjects. Additionally, the power consumption in the High Beam mode is only 17 W, reducing the power load on the drone and helping to maintain the flight time.

Reliable and Intuitive

Payload Protection

Zenmuse S1 is equipped with multiple protection mechanisms for temperature, overcurrent, power, and more, enhancing the product's reliability and lifespan.

Burn Protection

Zenmuse S1 features a plastic casing with a contact surface temperature that does not exceed 50 Degree C (122 Degree F), effectively preventing burn risks.

Eye Protection

When the drone is not in flight, Zenmuse S1 automatically dims the light to 40% of its maximum brightness to prevent glare and protect the operator's vision.

Efficient Remote Controller Shortcuts

Zenmuse V1 supports customizable shortcuts of the remote controller, allowing buttons to be set for brightness adjustment, turning the light on/off, or lighting mode changes. This makes operation convenient and intuitive, significantly enhancing the user experience.

Strong Environmental Adaptability

With an IP54 rating for dust and water resistance, Zenmuse S1 can operate in ambient temperatures ranging from -20 Degree to 40 Degree C (-4 Degree to 104 Degree F), making it adaptable to various operating environments.

Flexible Mounting, Lightweight Build

Zenmuse S1 can be mounted to any gimbal connector of the single downward gimbal, dual downward gimbals, or the single upward gimbal, accommodating various operational needs. Weighing only 0.76 kg, it is compact and easy to carry.

Mobile SDK

With Mobile SDK, users can quickly integrate Zenmuse S1's features into their self-developed mobile apps, unlocking the capabilities of your drone platform to meet specialized needs.

Technical Specifications:

Rated Power: 68 W
Supported Aircraft: Matrice 300 RTK (requires DJI RC Plus), Matrice 350 RTK
Eye Safety Class: IEC 62471: Risk Group 1
Shell Temperature: <122° F (50° C, plastic shell)
Ingress Protection Rating: IP54

Operating Temperature: -4° to 104° F (-20° to 40° C)
Storage Temperature: -4° to 140° F (-20° to 60° C)

Gimbal
Stabilization System: 3-axis (tilt, roll, pan)
Angular Vibration Range: Hover ±0.01°, Flight ±0.02°
Mounting: Detachable DJI SKYPORT
Mechanical Range: Tilt -129° to +73°, Roll ±55.8°, Pan ±327°
Controllable Range: Tilt -120° to +60°, Pan ±320°
Operation Mode: Follow / Free / Re-center

Illuminance
Maximum Central Illuminance: 35 lux @ 328.08' (100 m) (Both On mode)
Low Beam Central Illuminance: 13 lux @ 328.08' (100 m)
High Beam Central Illuminance: 30 lux @ 328.08' (100 m)
Effective Illumination Angle: 15 ±1° (Low Beam/Both On), 4 ±0.5° (High Beam)
Typical Color Temperature: 6500K (Low Beam), 7500K (High Beam)
Dimming Mode: Analog dimming
Effective Illumination Distance: 1,640.42' (500 m) (Both On mode)

Basic Features
Lighting Control: On/off, brightness adjustment
Strobe Mode: 5 Hz
Lighting Mode: Low Beam, High Beam, Both On
Remote Controller Buttons: Can control on/off, brightness, or lighting mode
Gimbal Synchronization: Supports synchronized control with other gimbal-equipped payloads

Special Features
Eye Protection: Automatically limits brightness to 40% when not in flight
Payload Protection: LED/LEP temperature protection, overcurrent protection, and power protection

Dimensions (L x W x H): 4.92 × 5.98 × 6.73" (125 × 152 × 171 mm)
Weight: 26.80 oz (760 g) ±10 g
