DJI Matrice 4D: Advancing Capability, Accuracy, and Autonomous Operations

The introduction of the innovative DJI Dock 3 brings forth two formidable aerial platforms-the DJI Matrice 4D-designed for continuous autonomous operations. These models expand upon the Matrice 4 Series foundation, providing enhanced flight capabilities, durability, and imaging systems.

While both platforms deliver remarkable features, the DJI Matrice 4D emerges as a comprehensive solution for precision mapping, detailed inspections, and specialized operational requirements. Discover its primary capabilities below.

Features:

• Achieve more with a 54-minute max flight time, ideal for extensive aerial surveys and inspections.
• Capture stunning detail with the Matrice 4D's 20MP wide-angle camera for professional-grade imagery.
• Experience reliable control with a max 25km transmission range, perfect for long-distance operations.
• Navigate confidently using GPS, BeiDou, Galileo, QZSS, & GLONASS for precise drone positioning.
• Ensure operational safety with advanced obstacle avoidance, reducing risks during complex missions.
• The DJI Matrice 4D offers ease of use with intuitive controls for both new and experienced pilots.

Core Capabilities of the DJI Matrice 4D

Designed for professionals requiring accuracy, productivity, and robustness, the DJI Matrice 4D sets new benchmarks for commercial drone technology with its sophisticated features.

Superior Flight Capabilities

• Wind Resistance: Maintains stability in winds reaching 12 m/s
• Extended Flight Duration: Delivers maximum flight time of 47 minutes, expanding to 54 minutes during forward flight
• IP55 Rating: Engineered to resist dust and water infiltration for all-weather deployment
• Anti-Ice Propellers: Sustains performance in freezing conditions with reduced noise output

State-of-the-Art Imaging Technology

• Wide-Angle Camera: Incorporates a 4/3 CMOS sensor, 20MP resolution, and mechanical shutter for exceptional image clarity
• Medium Tele Camera: Utilizes a 1/1.3-inch CMOS sensor and 48MP resolution for intermediate inspection tasks
• Tele Camera: Includes a 1/1.5-inch CMOS sensor, 48MP resolution, and zoom capability extending to 250m
• Laser Range Finder: Determines distances up to 1,800m with exceptional precision

Cutting-Edge Safety and Obstacle Detection

• LiDAR and millimeter-wave radar enable 12mm-level wire detection for secure navigation
• Multi-directional obstacle sensing improves operational safety in limited visibility environments
• AI-enhanced flight and intelligent tracking optimize subject identification and surveillance

Improved Night Operation and Image Stabilization

• Four low-light fisheye lenses deliver superior nighttime visibility
• Night Scene Mode: Produces full-color imagery in challenging lighting conditions
• Advanced stabilization: Guarantees steady image capture even during maximum zoom operations

Efficient Integration with DJI Dock 3

Combining the DJI Matrice 4D with DJI Dock 3 creates unparalleled efficiency and automation for remote aerial operations.

• 24/7 Autonomous Missions: Facilitates independent takeoff, landing, and recharging
• Cloud-Based Mission Planning: Leverage DJI FlightHub 2 for automated flight route management
• Versatile Deployment: Functions from stationary positions or vehicle-mounted docks for quick response
• Dual-Drone Coordination: Enables continuous aerial monitoring with synchronized multi-drone operation

Industry Applications

The DJI Matrice 4D addresses requirements across numerous sectors with its advanced capabilities.

Public Safety and Emergency Response

• Search and Rescue: Locates missing individuals using high-resolution imaging
• Firefighting: Evaluates wildfire conditions and hazardous areas in real time

Infrastructure and Industrial Inspections

• Energy Sector: Examines power lines, substations, and renewable energy installations
• Roads and Bridges: Assesses structural integrity safely and efficiently
• Oil and Gas: Performs pipeline and refinery inspections with reduced operational interruption

Mapping and Surveying

• Geospatial Mapping: Creates 3D models and highly accurate orthophoto maps
• Urban Planning: Gathers essential data for metropolitan infrastructure development

Water Resource Management: Supervises dam safety and flood-susceptible regions

Maritime and Border Patrol

• Coastal Surveillance: Identifies unauthorized activities and environmental shifts
• Port Security: Oversees vessels and facilities for regulatory compliance and safety

The DJI Matrice 4D embodies the next evolution in commercial drone technology, delivering exceptional accuracy, dependability, and automation. Whether integrated with DJI Dock 3 for autonomous operations or independently deployed with DJI RC Plus 2 Enterprise, it delivers superior aerial intelligence across diverse industries.

Technical Specifications:

Number of Rotors: 4
Configuration: Drone with Camera
Edition: Standard
FAA Registration (Non-Commercial Usage): Required
Features: Camera Included
Kit Style: Base
Model: Matrice 4D
Skill Level: Enterprise

Color: White
Maximum Flight Time: 54 minutes
Takeoff Weight: Up to 4.6 lbs (2.0 kg)
Max Ascent Speed: 6 m/s (Normal Mode), 10 m/s (Sport Mode)
Max Descent Speed: 6 m/s (Normal Mode), 8 m/s (Sport Mode)
Max Horizontal Speed: Normal Mode (Obstacle Sensing Enabled) 15 m/s forward, 12 m/s backward, 10 m/s sideways; Sport Mode 21 m/s forward, 19 m/s backward, 15 m/s sideways
Max Wind Speed Resistance: 12 m/s (during operation, takeoff, or landing)
Max Takeoff Altitude: 21,325' (6500 m)
Max Hovering Time: 47 minutes
Max Pitch Angle: 25° (Normal Mode), 30° (Sport Mode)
Max Flight Distance: 43 km
Max Angular Velocity: 200°/s
Global Navigation Satellite System: GPS + BeiDou + Galileo + QZSS + GLONASS
Hovering Accuracy: Vertical ±0.1 m (Vision), ±0.5 m (GNSS), ±0.1 m (RTK); Horizontal ±0.3 m (Vision), ±0.5 m (GNSS), ±0.1 m (RTK)
Operating Temperature: -4° to 122° F (-20° to 50° C)
IP Rating: IP55
Recommended microSD Cards: U3/Class 10/V30 or above, exFAT format; Lexar 1066x 64GB/128GB/256GB/512GB, Kingston Canvas Go! Plus 64GB/128GB/256GB/512GB

Camera System
Wide-Angle: 20 MP, 4/3 CMOS, 24 mm-equivalent, f/2.8–f/11, focus 1 m–∞, lens defogging supported
Medium Tele: 48 MP, 1/1.3-inch CMOS, 70 mm-equivalent, f/2.8, focus 3 m–∞, lens defogging supported
Tele: 48 MP, 1/1.5-inch CMOS, 168 mm-equivalent, f/2.8, focus 3 m–∞, lens defogging supported
ISO Range: Normal 100–25600; Night Scene Wide 100–204800, Medium Tele 100–409600, Tele 100–409600
Shutter Speed: Wide 2–1/8000 s (electronic), 2–1/2000 s (mechanical); Medium Tele 2–1/8000 s; Tele 2–1/8000 s
Max Image Size: Wide 5280×3956, Medium Tele 8064×6048, Tele 8192×6144
Still Photography Modes: Single, Timed, Smart Capture, Panorama (Wide); Single, Timed, Smart Capture (Medium Tele/Tele)
Photo Format: Wide JPEG/DNG, Medium Tele JPEG, Tele JPEG
Video Format: MP4 (H.264/H.265, CBR/VBR)
Max Video Bitrate: H.264 60 Mbps, H.265 40 Mbps
Digital Zoom: Tele 16× (112× hybrid)

Gimbal: 3-axis mechanical (tilt, roll, pan)
Mechanical Range: Tilt -140° to +50°, Roll -52° to +52°, Pan -65° to +65°
Controllable Range: Tilt -90° to +35°, Pan not controllable
Max Control Speed (tilt): 100°/s
Angular Vibration Range: ±0.005°

Sensing: Omnidirectional binocular vision + 3D infrared sensor (downward)
Forward: Measurement 0.5–20 m, Detection 0.5–200 m, Effective Speed ≤15 m/s, FOV H95° V90°
Backward: Measurement 0.5–20 m, Effective Speed ≤12 m/s, FOV H95° V90°
Lateral: Measurement 0.5–16 m, Effective Speed ≤10 m/s, FOV H90° V90°
Upward: Measurement 0.5–20 m, Effective Speed ≤6 m/s, FOV H95° V90°
Downward: Measurement 0.5–16 m, Effective Speed ≤6 m/s, FOV H90° V95°
Operating Environment: Forward/Backward/Upward/Downward surfaces with clear patterns, lux >0.1; Lateral surfaces diffuse reflective >20% reflectivity, lux >6

Video Transmission: DJI O4+ Enterprise
Live View: 720p/30fps or 1080p/30fps (DJI RC Plus 2 Enterprise), 540p–1080p/30fps (DJI Dock 3 & FlightHub 2)
Operating Frequency: 2.400–2.4835 GHz, 5.150–5.250 GHz (CE: 5.170–5.250 GHz), 5.725–5.850 GHz
Transmitter Power (EIRP): 2.4 GHz <33 dBm (FCC), <20 dBm (CE/SRRC/MIC); 5.1 GHz <23 dBm (FCC/CE); 5.8 GHz <33 dBm (FCC/SRRC), <14 dBm (CE)
Max Transmission Distance: FCC 25 km, CE/SRRC/MIC 12 km
With interference: Strong 1.5–5 km, Medium 5–15 km, Weak 15–25 km
Lowest Latency: 100 ms aircraft to dock, additional network factors dock to FlightHub 2

Battery: 6768 mAh, 22.14 V, LiNiMnCoO2, 149.9 Wh, Quantity 1

Dimensions: 14.8 × 16.38 × 8.36" (37.77 × 41.62 × 21.25 cm) without propellers
Weight: Approx. 4.07 lbs (1.85 kg)
