Dahua Europe 8-port Unmanaged Desktop Switch with 4-port PoE 1.0.01.20.10683

Dahua Europe 8-port Unmanaged Desktop Switch with 4-port PoE 1.0.01.20.10683

Features

• Intelligent PoE

• Hi-PoE 60W (orange port)

• 8-pin assignment PoE power supply

• Long distance PoE

• PoE watchdog

• Wide working temperature

Specifications

Hardware Feature

• Ethernet Port:

  • Port 1-4: 4 × RJ-45 10/100 Mbps (PoE)
    Port 5-8: 4 × RJ-45 10/100 Mbps

• Power Supply: 48 V–57 V DC

• Operaing Temperature: –10 °C to +55 °C (+14 °F to + 131 °F)

• Operating Humidity: 5%–95% (RH)

• Storage Temperature: –20 °C to + 70 °C (–4° F to + 158 °F)

• Storage Humidity: 5%–95% (RH)

• Power Consumption:

  • Idling: 0.8 W

  • Full load: 60 W

PoE

• PoE Standard: IEEE802.3af; IEEE802.3at; Hi-PoE

• PoE Power: 60 W

• Power Consumption Management: Yes

• PoE Pin Assignment: 1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-)

• Long Distance PoE: Supports 250 m (820.21 ft)

Performance

• Switching Capacity: 1.8 Gbps

• Packet Forwarding Rate: 1.19 Mpps

• Packet Buffer Memory: 768 Kbit

• MAC Table Size: 2K

• Communication Standard: IEEE802.3; IEEE802.3u; IEEE802.3x

General

• Statics Protection:

  • Air discharge: 8 kV

  • Contact discharge: 6 kV

• Thunder-proof:

  • Common mode: 4 kV

  • Differential mode: 2 kV

• Net Weight: 490 g (1.08 lb)

• Product Dimensions: 190 mm × 100 mm × 30 mm (7.48" × 3.93" × 1.18") (W × L × H)
