Corsair AX1600i 80 Plus Titanium 1600W Power Supply Unit CP-9020087-WW

Corsair AX1600i 80 Plus Titanium 1600W Power Supply Unit CP-9020087-WW

THE WORLD’S BEST PSU GETS BETTER

The CORSAIR AX1600i is the ultimate digital ATX power supply, built using only the best components and state-of-the-art gallium nitride transistors to deliver more than 94% efficiency.

Features:

• 1600W Maximum Power
• 80 Plus Titanium Certified
• Fully Modular
• 50°C Continuous Output Rated Temperature
• 1x ATX, 2x EPS Connector
• 3x Four Pin Peripheral, 8x PCIe Connectors
• 5x SATA Connectors
• Fluid Dynamic Fan Bearing
• Sleeved Low Profile Black Cables
• 100% Japanese 105°C Capacitors
• Zero RPM Fan Mode
• 10 Year Warranty

1600W OF ULTIMATE POWER

Delivers 1600W of continuous, ultra-stable, 80 PLUS Titanium efficient power.

TOP TIER COMPONENTS

100% 105°C Japanese electrolytic capacitors, top-specification internal components and digital design deliver over 94% efficiency.

THE ONLY CONSUMER PSU WITH GALLIUM NITRIDE TRANSISTORS

Totem-pole PFC Gallium Nitride (GaN) transistors for superior efficiency in a smaller form-factor.

WORLD CLASS ELECTRICAL PERFORMANCE

Incredibly stable voltages and ultra-low ripple noise.

Technical Specifications:

Special Technology: DSP, GaN Totem Pole PFC
PSU Form Factor: ATX
Continuous Power: 1600 W
Efficiency Rating: 80 PLUS Titanium
MTBF: 100,000 hours
Warranty: 10 Year
Weight: 5.15 kg
Dimensions: 150 mm × 86 mm × 200 mm
Modular: Fully
Cable Type: Low-Profile, All Black
Zero RPM Mode: Yes
Fan Size: 140 mm
Fan Bearing Technology: Fluid Dynamic Bearing

Connectors:

• ATX Connector: 1
• EPS Connector: 2
• PATA Connector: 9
• SATA Connector: 16
• Floppy Connector: 2
• PCIe Connector: 10
• Protections:
• Over Voltage Protection (OVP)
• Under Voltage Protection (UVP)
• Short Circuit Protection (SCP)
• Over Temperature Protection (OTP)
• Over Power Protection (OPP)

Compatibility:

• PSU conforms to ATX12V v2.4 and EPS 2.92 standards
• Backward compatible with ATX12V 2.2 and ATX12V 2.01 standards
• Multi-GPU Ready
• Single / Multiple 12V Rail Toggle: Yes
• Intel C6/C7 Sleep State Compatible: Yes
• Modern Standby: No

What's in the Box:

• AX1600i Digital ATX Power Supply
• User manual
• Cable ties
• “Velcro” cable straps
• Mounting screws
• CORSAIR case b

*Note: AC Power Cord Not included
