Cambium ePMP Force 300-25L AC Wave 2 25dBi Subscriber Module Antenna EPMP-F300-25L

Cambium ePMP Force 300-25L AC Wave 2 25dBi Subscriber Module Antenna EPMP-F300-25L

The Cambium Networks ePMP Force 300-25L is an outdoor fixed wireless subscriber module designed to deliver high-performance broadband connectivity in challenging and high-interference RF environments. Providing over 400Mbps of real user data throughput, wide-band 4910–6200MHz operation and support for 20, 40 and 80MHz channel widths, it provides a flexible platform for fixed wireless broadband deployments. An IP55-rated outdoor enclosure, wide operating-temperature range and 128-bit AES security make it suitable for reliable outdoor network installations.

Key Features

• Over 400Mbps throughput: Designed to deliver more than 400Mbps of real user data for high-performance fixed wireless broadband connectivity.
• Wide-band 4910–6200MHz operation: Provides flexible frequency selection across a broad operating range for fixed wireless deployments.
• 20, 40 and 80MHz channels: Multiple channel-width options allow operators to balance spectrum availability and network performance.
• 5MHz channel spacing: Configurable channel spacing provides additional flexibility when planning RF deployments.
• High-interference operation: Specifically designed by Cambium Networks for reliable performance in challenging RF environments.
• 128-bit AES encryption: CCMP-mode encryption helps protect wireless network communications.
• IP55 outdoor enclosure: Designed for permanent outdoor deployment with protection against environmental exposure.
• Wide operating temperature: Supports operation from -30°C to 60°C for deployment across demanding environmental conditions.

Over 400Mbps Real User Throughput

The ePMP Force 300-25L is designed to provide more than 400Mbps of real user data throughput, making it suitable for high-speed fixed wireless broadband connections. Its performance is designed specifically for environments where RF interference can make reliable broadband delivery challenging.

Wide-Band 4910–6200MHz Operation

A wide operating frequency range from 4910MHz to 6200MHz gives network operators flexibility when selecting available spectrum. Channel spacing can be configured in 5MHz increments, helping accommodate different RF environments and deployment requirements.

Flexible Channel Widths

The Force 300-25L supports 20MHz, 40MHz and 80MHz channel widths. This allows network designers to select an appropriate balance between available spectrum, interference conditions and required wireless throughput.

Designed for Challenging RF Environments

Cambium Networks specifically designed the ePMP Force 300-25L for operation in high-interference environments. Its flexible spectrum configuration and receive sensitivity characteristics help support dependable fixed wireless connectivity where competing RF signals may be present.

Outdoor-Ready Construction

An IP55-rated enclosure allows the Force 300-25L to be deployed outdoors, while its specified operating-temperature range of -30°C to 60°C supports installation across a broad range of climates. The unit weighs approximately 1.6kg and measures 280 × 470 × 470mm.

Technical Specifications

What’s in the Box:

• 1 × Cambium Networks ePMP Force 300-25L

Deploy reliable high-speed fixed wireless broadband in challenging RF environments with over 400Mbps of real user data throughput, wide-band 4910–6200MHz operation, flexible 20/40/80MHz channel widths and an IP55 outdoor-rated design using the Cambium Networks ePMP Force 300-25L.
