ASRock B650E Steel Legend Wifi AMD Socket AM5 ATX Motherboard B650E-STEELLEGEND

ASRock B650E Steel Legend Wifi AMD Socket AM5 ATX Motherboard

ASRock B650E Steel Legend WiFi AMD B650E Ryzen Socket AM5 ATX Desktop Motherboard

Optimized VRM Design
Dr.MOS design features the latest SPS (Smart Power Stage) technology. It’s optimized for monitoring current and temperature of each phase, thus delivering smoother and neater power to the CPU with enhanced performance and OC capability.

Premium PCB Design
The server grade low loss PCB improves signal integrity, allowing motherboard to support PCIe 5.0 for both graphics card and M.2 SSD, it also improves memory OC potential to deliver the most extreme memory performance.

Extreme Overclocking Performance
Derived from the “built for stable and reliable” designing concept, ASRock does not compromise on any details. All B650E motherboards are built with 8-Layer and premium low-loss materials, enthusiasts are able to enjoy the boost of DDR5 memory overclocking performance up to 6600MHz and beyond by enabling the pre-tested profiles. Make sure the memory modules are AMD EXPO/ Intel XMP capable and overclocking can be made so affordable, satisfying and absolutely no sweat at all.

Specifications:

• ATX Form Factor
• AMD B650 Chipset
• Socket AM5
• 4x DDR5 DIMM Slots, Supports Up To 128GB
• Supports Up to DDR5-6400MT/s (OC)
• Supports AMD EXPO DDR5 Modules
• 1x PCIe 5.0 x16 Slot
• 1x PCIe 3.0 x4 Slot
• 1x M.2 2280 PCIe 5.0 x4 NVMe SSD Slot
• 2x M.2 2280 PCIe 4.0 x4 NVMe SSD Slots
• 2x SATA 3.0 6.0Gbps Ports
• 1x USB 10Gbps Type-C Port
• 1x USB 10Gbps Type-A Port
• 4x USB 5Gbps Type-A Ports
• 2x USB 2.0 Ports
• 1x HDMI 2.1, 1x DisplayPort 1.4, 1x Optical S/PDIF Port
• 2x 3.5mm Audio Jacks (Line Out, Microphone)
• Realtek Dragon RTL8125BG 2.5 Gigabit Ethernet RJ-45 LAN
• AMD WiFi 6E 2×2 MIMO Tri-Band Adapter, Bluetooth 5.3
• Realtek ALC897 High Definition Audio CODEC
• ASRock Dragon 2.5G LAN Software
• ASRock Polychrome RGB Sync
• ASRock Surface-Mount Tech PCIe 5.0 Slots
• ASRock LED Diagnostic Display
• ASRock APP Shop
