Antec Gen5 850W 80 Plus Gold Fully Modular ATX3.0 Power Supply NE850G M

Antec Gen5 850W 80 Plus Gold Fully Modular ATX3.0 Power Supply

Antec NeoEco 850W Gold ATX3.0 Modular PSU

Introducing our NE850G M ATX 3.0 power supply, designed with the ultimate performance and stability in mind for the gaming and enthusiast market. With advanced features like ATX 3.0 and high-quality JP capacitors, unparalleled stability, and 80 PLUS® Gold-certified efficiencies, you can expect peak performance from your system. The PhaseWave™ Design ensures steady power output, while the 120mm FDB Silence Fan offers quiet cooling. The power supply is also 100% Modular, allowing for easy cable management and customization. The Zero RPM Manager enables advanced thermal control, ensuring the optimal balance between silent operation and efficient cooling. The CircuitShield™ suite of industrial-grade protections provides safe and reliable power delivery in any environment. The NE850G M ATX 3.0 is the perfect choice for building a reliable and efficient PC system for gamers and professionals.

ATX 3.0 & PCIe 5.0 Compatible

Our new NEG M ATX 3.0 Series power supplies meet the high standards of the ATX 3.0 standard for reliability and power efficiency, which are formally certified for ATX 3.0 compliance, ensuring the utmost level of quality and performance. The included PCIe 5.0 12VHPWR GPU cable enables seamless compatibility with modern graphics cards, such as the NVIDIA® GeForce RTX™ 40 Series.

High-Quality Japanese Capacitors

Equipped with high-quality Japanese capacitors, our power supplies achieve unprecedented tight voltage regulation and minimal ripple and noise, maximizing your system's performance.

PhaseWave TM Design

Introducing our PhaseWave™ Design, a server-classLLC design featuring synchronous rectification based on a DC-DC topology. This design ensures unparalleled power delivery efficiency and stability for your system.

10-Year Warranty

The new PSU line from Antec pushes the standard for excellence with the circuit shield suite of industrial protections and is backed by a 10-year warranty.

Specifications:

• Modularity: Fully Modular
• Output Capacity: 850W
• Input Voltage: 100-240 V
• Input Current: 10A-5A
• Input Frequency Range: 50Hz-60Hz
• PFC: Active PFC
• Power Good Signal: 100-150ms
• Protection: OCP, OVP, UVP, SCP, OPP, OTP, SIP, NLO
• Regulatory: cTUVus / TUV / CB / RCM / CE / FCC / BIS / BSMI / KC / UKCA / ICES
• Fan: 120mm FBD Silent Fan
• Certifications: 80 Plus Gold
• Connectors
  • 1 x 24-pin MB (20+4)
  • 1 x 16-pin PCIE 5.0 12VHPWR (12+4)
  • 2 x 8-pin CPU (4+4)
  • 4 x 8-Pin PCI-E (6+2)
  • 12 x SATA
  • 4 x Molex
• Product Dimensions: 14 x 15 x 8.6 cm
