Alcatel-Lucent OmniSwitch 2260 WebSmart 24-port PoE Switch OS2260-P24-IN

Alcatel-Lucent OmniSwitch 2260 WebSmart 24-Port PoE+ Switch

The Alcatel-Lucent OmniSwitch 2260 OS2260-P24-IN is a WebSmart+ Gigabit Ethernet switch designed for small and medium-sized business networks, high-speed desktop connectivity and unified communications. Its 24 Gigabit Ethernet PoE+ ports can carry network data and electrical power to compatible IP phones, wireless access points, surveillance cameras and other powered devices, helping to reduce separate cabling and power requirements.

Powered by the field-proven Alcatel-Lucent Operating System, the switch combines a straightforward browser-based management interface with useful security, Quality of Service and network monitoring capabilities. Four fixed Gigabit SFP uplink ports provide flexible fibre connectivity for linking network areas or connecting to compatible upstream equipment.

Reliable Connectivity for Business Networks

Each of the 24 RJ45 ports supports automatic 10/100/1000 Mbps operation, while Auto MDI/MDIX simplifies installation with compatible Ethernet cabling. Wire-rate switching and a forwarding rate of up to 41.7 million packets per second help the switch handle everyday voice, video and data traffic efficiently.

PoE+ for Connected Devices

Support for IEEE 802.3af PoE and IEEE 802.3at PoE+ allows compatible devices to receive power through their network cables. A total PoE budget of 195 W supports a range of business equipment, while configurable port priorities and dynamic power allocation help distribute available power according to device requirements.

Simplified Network Management

The WebView 2.0 browser interface provides an accessible way to configure and monitor the switch. Administrators can also use supported command-line and SNMP management options, while integration with Alcatel-Lucent OmniVista platforms supports broader network oversight where required.

Security and Traffic Control

Network access can be managed using features such as IEEE 802.1X authentication, MAC-based authentication and learned port security. VLAN, Access Control List and Quality of Service capabilities help administrators separate traffic, apply access policies and prioritise time-sensitive services such as voice and video.

Key Features:

• Twenty-four 10/100/1000Base-T RJ45 PoE+ ports provide Gigabit connectivity and power for compatible network devices.
• Four fixed 1 Gigabit SFP uplink ports support compatible fibre or copper transceivers.
• A 195 W PoE budget supports IEEE 802.3af and IEEE 802.3at powered devices.
• WebView 2.0 offers convenient browser-based configuration and monitoring.
• Static IPv4 and IPv6 routing supports practical Layer 2+ network deployments.
• VLAN, QoS, link aggregation and multicast features help manage business network traffic.
• IEEE 802.1X, MAC authentication and access control capabilities help protect the network edge.

Technical Specifications:

Build a manageable Gigabit network and power compatible connected devices from one practical switch by adding the Alcatel-Lucent OmniSwitch 2260 OS2260-P24-IN to your cart today.
