Solarix Ultra Power 48V 20A Lithium Ion Phosphate Battery Charger SOLUPLIBC

Solarix Ultra Power 48V 20A Lithium Ion Phosphate Battery Charger SOLUPLIBC

The Solarix Ultra Power 48V 20 A Lithium Ion Phosphate Battery Charger is designed to optimise the performance and lifespan of Lithium Ion Phosphate (Lifepo4) batteries and can safely achieve a 100% State of Charge. This 48V 20 A battery charger operates from mains AC 220-240V as input, supplying up to 20A charging output suitable for nominal 48V LiFePO4 battery banks. The charger's built-in protection technology provides protection against Over Voltage and Over Current output, Short Circuit making it very safe to use. With energy efficiency > 85%, the charger produces less heat, delivers more energy and allows faster charging in less than 2 hours . The Lightweight Aluminium Casing is equipped with active ventilation fan system that allows the charger to be used in harsh environments or hot climates

Highlights

• Ultra Power Lithium Ion Phosphate Battery Charger
• 4 Steps Charging
• Maximum Charging Output Voltage(CV) 54.8V
• Maximum Constant Output Current (CC): 20 Amps
• AC Input Voltage 220VAC Max 240VAC
• AC Input Frequency 50 Hz
• Power Efficiency >85% At Full Load
• Output Power1000W (1380W Maximum Output)
• Lightweight Aluminium Casing With Ventilation Fan
• 2x Round 8.2mm Output Connector Lugs

Specifications

• Product Type 4 Steps Charging System
• Input Voltage Min 220VAC to Max 240VAC
• Output Power1000W (1380W Maximum Output)
• Constant Charge Voltage Min 58.1VDC to Max 58.7VDC
• Constant Current 20A
• Charge Complete Current VDC Min 1.2A to Max 1.8A
• Power Efficiency >85% At Full Load
• Colour Black
• Dimensions Length 210mm x W-125mm x H-70mm
• Weight 3.0Kg
