Xiaomi AX1500 Wi-Fi Range Extender White DVB4514GL

Xiaomi AX1500 Wi-Fi Range Extender White DVB4514GL

The Xiaomi Wi-Fi Range Extender AX1500 is a compact Wi-Fi 6 solution designed to eliminate weak signal areas and deliver fast, stable connectivity throughout your home. With combined speeds of up to 1501Mbps across dual-band 2.4GHz and 5GHz networks, it ensures smooth streaming, reliable work-from-home performance, and responsive online gaming.

EasyMesh compatibility enables seamless whole-home coverage with automatic signal switching, while dual high-gain antennas extend coverage into hard-to-reach areas. A built-in Gigabit Ethernet port supports wired connections or Access Point mode, and setup is simple via the Xiaomi Home app. Designed for performance, security, and ease of use, it’s an efficient way to upgrade your home network.

• Next-generation wireless performance with improved efficiency and reduced latency.
• Up to 300Mbps on 2.4GHz and 1201Mbps on 5GHz for streaming, gaming and smart devices.
• Creates a seamless mesh network for full-home Wi-Fi coverage and automatic roaming between nodes.
• 1 × 10/100/1000Mbps LAN port for wired devices or Access Point mode operation.
• Enhances signal strength and extends coverage to previously unreachable areas.
• Supports Range Extender Mode, Mesh Mode and Access Point Mode for flexible deployment.
• Supports WPA-PSK, WPA2-PSK and WPA3-SAE encryption, plus SSID hiding for improved network security.
• Manage and configure your network easily via Android and iOS devices.

Specifications:
2.4GHz Wi-Fi: 2×2 (supports up to IEEE 802.11n protocol with a theoretical max rate of 300Mbps)
5GHz Wi-Fi: 2×2 (supports up to IEEE 802.11ax protocol with a theoretical maximum rate of 1201Mbps)
Antenna: 2 high-gain antennas
Heat Dissipation: Natural heat dissipation
Network Port: 1 × 10/100/1000Mbps LAN port
LED Indicator: System indicator, Signal indicator
System Reset Button: x1
WPS/Mesh Networking Button: x1
Protocol Standard: IEEE 802.11 a/b/g/n/ac/ax, IEEE 802.3/3u/3ab
Dual-band: 2.4GHz, 5GHz
Modulation:
11b: DSSS: DBPSK (1Mbps), DQPSK (2Mbps), CCK (5.5/11Mbps)
11a/g: OFDM: BPSK (6/9Mbps), QPSK (12/18Mbps), 16QAM (24/36Mbps), 64QAM (48/54Mbps)
11n: MIMO-OFDM:BPSK,QPSK,16QAM,64QAM Data rate: MCS0-MCS15
11ac: MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM, 256QAM
11ax: MIMO-OFDMA: BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM
Working Mode: Range Extender mode, Mesh mode, Access Point (AP) mode
Wi-Fi Encryption: WPA-PSK/WPA2-PSK/WPA3-SAE, SSID hidden
Management Applications: Xiaomi Home app (Android, iOS)
Working Environment Temperature: 0 to 40°C
Operating Humidity: 10% to 90% RH (non-condensing)
Storage Temperature: -40°C to 70°C
Storage Humidity: 5% to 90% RH (non-condensing)
Colour: White
Product Dimensions: 8.4 x 8.2 x 16.8 cm

What's in the box:

• Xiaomi Wi-Fi Range Extender AX1500 – White x1
• User Manual x1
