Tenda W12 AC1200 Wall Plate Access Point

Tenda W12 AC1200 Wall Plate Access Point

Seamlessly Blends with your Decoration

11AC 1200Mbps Dual-band Gigabit In-Wall AP

Dual-band Gigabit Wired/Wireless

With a network port rate of up to 1000M and a wireless rate of up to 1200M, supporting Gigabit-class fiber broadband, W12 helps hotel rooms, meeting rooms, large suites/villas and entertainment venues enter the era of Gigabit WiFi.

With the latest WAVE 2.0 wireless technology
providing access for up to 50 devices

Support WAVE2.0 MU-MIMO technology, a single AP can communicate with every wireless device at the same time , 50 people can simultaneously enjoy online game or streaming videos without lag.

RF signal optimisation, full coverage for 2 rooms

Independent RF chip design, isolation of WiFi signal processing and power supply, zero electromagnetic interference, high-performance antenna. W12 can cover 2 side-by-side hotel rooms without dead points.

Band Steering(5G first) to guarantee network performance

Intelligent allocation of frequency bands to which wireless devices are connected, guiding 5GHz wireless devices to associate with 5GHz RF in priority, making the load of both 2.4GHz and 5GHz bands more balanced, avoiding network congestion caused by wireless terminals piling up on 2.4GHz channels, thus improving the performance of the entire wireless network.

Supports standard PoE power supply for easier installation

Using standard PoE power supply, no external power supply is required, each AP only needs one network cable to transmit data and power at the same time, no need to change the original wire layout.

Technical Specifications:

General

Model
W12

Category
In-Wall

Dimensions
86 × 86 × 32 mm

Maximum Number Of Clients
256

Recommended Number Of Clients
35

Hardware

Ethernet Interfaces

• 1 × 10/100/1000 Mbps Ethernet Port
• 1 × 10/100/1000 Mbps Ethernet Port (PoE)

Buttons
1 × Reset Button

LED Indicators
1 × SYS LED

Power Supply
PoE (802.3af)

Maximum Power Consumption
7.3 W

Antenna Gain
3 dBi

Frequency Range
2.4 GHz And 5 GHz

Wireless Standards And Protocols
IEEE 802.11b/g/n/a/ac (Wave 2)

Maximum Wireless Speed

• 2.4 GHz: 300 Mbps
• 5 GHz: 867 Mbps

Bandwidth

• 20 MHz
• 40 MHz
• 80 MHz

Maximum Transmission Power

• 2.4 GHz: 18 dBm
• 5 GHz: 17 dBm

Reception Sensitivity

• 2.4 GHz 802.11b: -88 dBm
• 2.4 GHz 802.11n (MCS7): -72.5 dBm
• 5 GHz 802.11a: -92.5 dBm
• 5 GHz 802.11n (MCS7): -72 dBm

Software Features

Operating Modes

• AP Mode
• Client + AP Mode

Maximum Number Of SSIDs

• 2.4 GHz: 6
• 5 GHz: 4

Wireless Features

• Hide SSID
• OFDMA
• Beamforming
• Fast Roaming (802.11k/v/r)
• MU-MIMO
• Adjustable Transmission Power
• Automatic Channel Selection
• AP Isolation
• Guest Network
• Connected Client Control
• RSSI Threshold
• Weak Signal Terminal Elimination
• Prioritize 5 GHz
• VLAN Tagging For SSID
• LED Control

Security Features

• WEP
• WPA
• WPA-PSK
• WPA2
• WPA2-PSK

Management And Maintenance

• Diagnostics Tool
• Scheduled Reboot
• Reboot At Specified Interval
• System Logs
• Firmware Upgrade
• Backup Configuration
• Restore Configuration
• Device Management Via M3 Or Tenda Router With AP Controller Feature

Network Settings

Default IP Address
192.168.0.254

Environmental

Operating Temperature
-10 °C To 45 °C

Operating Humidity
10% To 90% (Non-Condensing)

Storage Temperature
-30 °C To 70 °C

Storage Humidity
5% To 90% (Non-Condensing)
