Teltonika RUT271 RedCap 5G Industrial Router

Teltonika RUT271 RedCap 5G Industrial Router

The RUT271 is a Redcap 5G router, bridging the gap between 4G and full-capacity 5G. Supporting SA architecture, this 5G router can wirelessly support up to 50 end devices and features the low latency of 5G—at affordable pricing. The RUT271 supports Wi-Fi and is backward compatible with 4G LTE Cat 4. This industrial-grade RedCap 5G router is also equipped with WAN failover, two 10/100 RJ45 ports, a compact and durable design, and numerous other brilliant features for expert professional deployment.

Technical Specifications:

Mobile

Mobile module

• 5G Sub-6Ghz SA 223 Mbps DL, 123 Mbps UL
• 4G LTE Cat 4 – LTE 195 Mbps DL, 105 Mbps UL

3GPP Release
Release 17 RedCap

Status

• IMSI, ICCID, operator, operator state, data connection state, network type, bandwidth, connected band
• Signal strength (RSSI), SINR, RSRP, RSRQ, EC/IO, RSCP
• Data sent/received, LAC, TAC, cell ID
• ARFCN, UARFCN, EARFCN, MCC, and MNC

SMS

• SMS status, SMS configuration
• EMAIL to SMS, SMS to EMAIL
• SMS to HTTP, SMS to SMS
• Scheduled SMS, SMS autoreply
• SMPP

USSD
Supports sending and reading Unstructured Supplementary Service Data messages

Block/Allow list
Operator block/allow list (by country or separate operators)

Multiple PDN
Possibility to use different PDNs for multiple network access and services

Band management

• Band lock
• Used band status display

SIM PIN code management
SIM PIN code management enables setting, changing, or disabling the SIM card's PIN

APN
Auto APN

Bridge
Direct connection (bridge) between mobile ISP and device on LAN

Passthrough
Router assigns its mobile WAN IP address to another device on LAN

Wireless

Wireless mode

• 802.11b/g/n (Wi-Fi 4)
• Access Point (AP)
• Station (STA)

Wi-Fi security

• WPA2-Enterprise: PEAP, WPA2-PSK, WPA-EAP, WPA-PSK, WPA3-SAE, WPA3-EAP, OWE
• AES-CCMP, TKIP, Auto-cipher modes, client separation
• EAP-TLS with PKCS#12 certificates, disable auto-reconnect
• 802.11w Protected Management Frames (PMF)

SSID/ESSID
SSID stealth mode and access control based on MAC address

Wi-Fi users
Up to 50 simultaneous connections

Wireless Connectivity Features

• Wireless mesh (802.11s)
• Fast roaming (802.11r)
• BSS transition management (802.11v)
• Radio resource measurement (802.11k)

Ethernet

Ethernet Ports

• 2 x Ethernet ports (10/100 Mbps)
• Supports DHCP Client/Static IP, supports VLAN tagging (802.1Q)

Network

Routing

• Static routing, dynamic routing (RIP, OSPF)
• Routing based on destination/source address, interface, and firewall mark

NAT

• Source NAT, Destination NAT, one-to-one NAT, NAT rules based on source/destination address, port, protocol, and interface

Firewall

• Stateful packet inspection, customizable firewall rules based on IP, port, and protocol

DHCP

• DHCP server/client/relay, static DHCP bindings

DNS

• DNS server, DNS forwarding, DNS over HTTPS, dynamic DNS support

Security

IP filtering

• Based on source/destination IP, port, and protocol

MAC filtering

• Based on source MAC address

URL filtering

• Domain and keyword-based filtering

VPN

Supported protocols

• OpenVPN, IPsec, L2TP, GRE, PPTP, WireGuard

Authentication methods

• Username/password, pre-shared key, digital certificate

Tunneling options

• Site-to-site, client-to-site, multiple tunnel support

VPN passthrough

• Supported

QoS

Traffic shaping

• Bandwidth limit per interface, per IP, or per application

Prioritization

• Application and port-based traffic prioritization

Queue types

• FIFO, SFQ, RED, HFSC

Tools

Diagnostics

• Ping, traceroute, DNS lookup, packet capture

Monitoring

• Real-time bandwidth usage, system logs, event alerts

Remote management

• Web UI, SSH, SNMP, TR-069

Environmental

Operating temperature

• -40°C to 85°C

Humidity

• 10% to 90% non-condensing

Ingress Protection Rating

• IP30

Regulatory & Type Approvals

Regulatory

• CE, UKCA, FCC, IC (ISED), RCM, CB, WEEE

EMC Emissions & Immunity

Standards

CE/UKCA:

• EN 55032:2015 + A11:2020 + A1:2020
• EN 55035:2017 + A11:2020
• EN IEC 61000-3-2:2019 + A1:2021 + A2:2024
• EN 61000-3-3:2013 + A1:2019 + A2:2021
• EN 301 489-1 V2.2.3
• EN 301 489-17 V3.3.1
• EN 301 489-19 V2.2.1
• EN 301 489-52 V1.2.1

FCC/ISED(IC):

• 47 CFR Part 15 Subpart B
• ICES-003: Issue 7 (October 2020)

RCM:

• AS/NZS CISPR 32:2015 + A1

ESD

• EN 61000-4-2: 2009

Radiated Immunity

• EN IEC 61000-4-3:2020

EFT

• EN 61000-4-4: 2012

Surge Immunity (AC Mains Power Port)

• EN 61000-4-5: 2014 + A1:2017

CS

• EN 61000-4-6:2014

DIP

• EN 61000-4-11:2020

RF

Standards

CE/UKCA:

• Draft EN 301 908-25 V15.1.1_0.0.21
• EN 300 328 V2.2.2
• EN 301 908-1 V15.2.1
• EN 301 908-13 V13.2.1

RCM:

• AS/NZS 4268:2017+A1:2021
• AS/CA S042.1:2022
• AS/CA S042.4:2022
• AS/CA S042.5:2022+A1:2022

Standards (Wi-Fi 2.4 GHz, 5 GHz)

FCC:

• 47 CFR Part 15 Subpart C - § 15.247, Subpart E - § 15.407

IC (ISED):

• RSS-247 Issue 3 (August 2023)
• RSS-Gen Issue 5 (April 2018) Amendment 2 (February 2021)

RF Exposure

Standards

FCC:

• 47 CFR - § 2.1091
• 47 CFR - §1.1310
• KDB 447498 D04 Interim General RF Exposure Guidance v01

IC (ISED):

• RSS-102 Issue 6 (December 2023)

Safety

Standards

• CE: EN IEC 62368-1:2020 + A11:2020, EN IEC 62311:2020
• CB: IEC 62368-1:2018
• RCM: AS/NZS 62368.1:2022
