Globalsix Compatible Dell 40GbE QSFP+ SR4 850nm 150m MPO Transceiver Module 1PQSFP40GSRDEL

Globalsix Compatible Dell 40GbE QSFP+ SR4 850nm 150m MPO Transceiver Module 1PQSFP40GSRDEL

The QSFP+ module adopts 12 Fibers MTP/MPO Male connectors, reaching a link up to 150m over OM4 MMF (100m over OM3). This transceiver is compliant with IEEE 802.3 40GBASE-SR4 standard. At the same time, it is completely interoperable with all standard 40GBASE-SR4 interfaces. Digital diagnostics functions are also available via the I2C interface, as specified by the QSFP+ MSA, to allow access to real-time operating parametres. With its easy installation and hot-swappable design, this transceiver is ideal for various applications, including campus, data centre, cloud deployments, high-performance computing environments, and interconnections between switches, routers, servers, and transport equipment. Because the QSFP-SR4-40G does not support 4x10G breakout connectivity, see QSFP-4×10G-SR for such applications.

Features:

• Wide Compatibility: Compatible for Dell (DE) Networking 430-4593/407-BBOI. 40G Ethernet, Infiniband QDR, SATA/SAS3, IEEE 802.3ba standard, MSA Compliant.
• 40G QSFP+ Multi-Mode Transceivers: 40Gb/s data rate, MPO/MTP connector, 850nm Wavelength, the transmission distance up to 150m, working temperature: 0℃ ~ +70℃, Tx Power(dBm): -7 ~ +1, Rx Sens.(dBm): ＜ -9.5.
• Easy to use: Plug and play, hot-pluggable. DDM support: DDM allows you to monitor the critical information, to find out some potential problems. Widely used in fiber switches, routers, NIC, server or other fiber optic equipments with 40Gb QSFP+ ports.
• 100% high quality products: We always strictly control product quality, every module had been individually tested on switches before shipping, customers can rest assured to buy.
• After-sales Service: 30-day free return, 3-year warranty, lifetime technology support. We offer many compatible options, If you are not sure about the compatibility of your device, please feel free to email us. QSFPTEK is a manufacturer of SFP module, customized service is available.

Technical Specifications:

Cisco Compatible: QSFP-40G-SR4
Vendor Name: FS
Form Factor: QSFP+
Max. Data Rate: 41.25Gbps
Wavelength: 850nm
Max. Transmission Distance: 150m@OM4 / 100m@OM3
Connector: MTP/MPO-12 Male
Cable Type: MMF
Transmitter Type: VCSEL
Receiver Type: PIN
TX Power: -7.6 ~ 2.4dBm
Receiver Sensitivity: < -5.4dBm
Digital Optical Monitoring: Yes
Receiver Overload: 2.4dBm
Max. Power Consumption: ≤ 1.5W
Core Size: 50µm
Extinction Ratio: >3dB
Modulation: NRZ
Host FEC Supported: Yes
Modal Bandwidth: 2000 (OM3) MHz·km / 4700 (OM4) MHz·km
Operating Temperature: 0 to 70°C (32 to 158°F)
Protocols: IEEE 802.3 40GBASE-SR4, SFF-8436
