LinkQnet 2000VA 1200W Line-Interactive Tower UPS

LinkQnet 2000VA 1200W Line‑Interactive Tower UPS

The LinkQnet 2000VA/1200W Line‑Interactive UPS is an uninterruptible power supply designed to provide temporary battery backup and power protection for computers, networking equipment, and other electronic devices. Operating at 230 V AC / 50 Hz, it helps safeguard equipment from power outages, voltage fluctuations, and electrical disturbances.

With a capacity of 2000 VA / 1200 W, the unit can support several devices simultaneously, making it suitable for small office environments, workstations, or home IT setups. It uses line-interactive technology with automatic voltage regulation (AVR) to stabilise incoming power and reduce the need to switch to battery mode during minor voltage fluctuations.

The UPS incorporates an LED/LCD status display that provides real-time information such as input voltage, battery status, and load levels. This allows users to monitor system conditions and respond quickly to power events. The device typically includes multiple output sockets, USB and serial communication ports, and network protection ports, enabling integration with computers and network hardware for monitoring and controlled shutdown.

Internally, the system is powered by two 12 V 9 Ah sealed lead-acid batteries, which deliver short-term backup power during outages and typically recharge to around 90 % capacity within 6–8 hours. The UPS also includes protection features such as overload protection, over-charge protection, and deep-discharge protection to enhance reliability and battery lifespan.

Specifications:

Rated Power: 2000 VA / 1200 W

UPS Technology: Line-Interactive with AVR (Automatic Voltage Regulation)

Nominal Voltage: 220 / 230 / 240 VAC

Voltage Range: 162 – 290 VAC

Frequency Range: 50 Hz or 60 Hz ±1 Hz

Output Voltage: 220 / 230 / 240 VAC

Voltage Regulation (Battery Mode): ±10%

Frequency (Battery Mode): 50 Hz or 60 Hz ±1 Hz

Transfer Time: Typical 2–6 ms

Waveform (Battery Mode): Simulated sine wave

Battery Type: Sealed lead-acid

Battery Configuration: 12 V / 9 Ah

Recharge Time: 6–8 hours to approximately 90% capacity
