Uniview Uniarch UNV 5MP Indoor PTZ with IR and Warm Light Camera Uho-S3E-M3TD

Uniview Uniarch UNV 5MP Indoor PTZ with IR and Warm Light Camera Uho-S3E-M3TD

The Uniview Uniarch Uho-S3E-M3TD 3MP IP Camera delivers clear indoor video monitoring for homes and small businesses. It features a 3-megapixel sensor and a 4.0mm fixed lens, providing a standard field of view ideal for watching over entrances, hallways, or rooms.

Infrared LEDs enable night vision up to 10 metres in low-light conditions. The built-in MicroSD card slot supports up to 512GB of local storage for direct on-device video recording.

Features:

• 3MP resolution for clear image quality
• 4.0mm fixed lens for standard viewing angles
• IR night vision up to 10 metres
• MicroSD slot supporting up to 512GB
• Compact design for indoor use

Technical Specifications:

Sensor: 1/2.8" progressive scan CMOS, 3.0 megapixels. Minimum illumination is 0.02 lux (F2.0, AGC ON), 0 lux with IR on. Shutter supports Auto/Manual, 1 s to 1/100,000 s. WDR: DWDR. Signal-to-noise ratio >52 dB.

Lens: Fixed 4.0 mm F2.0 lens. Angle of view: Horizontal 89.4°, Vertical 46.9°, Diagonal 94.0°. Iris type: Fixed.

Illuminator: IR range up to 10 m, warm light up to 10 m, wavelength 850 nm. On/off control supports Auto/Manual.

Video: Compression formats include Ultra 265, H.265, and H.264. Main stream supports 3MP (2304×1296) at 25 fps, 2MP (1920×1080) at 30 fps, and 720P (1280×720) at 30 fps. Sub-stream supports 640×360, 2CIF (704×288), CIF (352×288) at up to 30 fps. Video bit rate ranges from 128 Kbps to 2048 Kbps. ROI supports up to 8 areas. Dual streams supported. Up to 2 OSDs and privacy mask supported (NVR only).

Image Features: White balance modes: Auto, Outdoor, Fine Tune, Sodium Lamp, Locked, Auto2. Digital noise reduction: 2D/3D DNR. Smart IR supported. Flip: Normal, Vertical, Horizontal, 180°. Defog: Digital Defog. HLC and BLC: N/A.

Events: Supports human body detection, motion detection, ultra motion detection (human/vehicle/pet), loud sound detection, and crying detection. Auto tracking supported. General functions include IP address filtering, access policy, ARP protection, RTSP/HTTP authentication, and user authentication.

Audio: Compression: G.711U/G.711A, bitrate 64 Kbps. Two-way audio supported with suppression. Sampling rate 8 kHz.

Storage: Edge storage via Micro SD up to 512 GB, network storage with ANR support.

Network: 2.4G Wi-Fi (IEEE802.11b/g/n/ax) with built-in antenna. Protocols supported include IPv4, TCP, UDP, DHCP, RTSP, DNS, DDNS, NTP, HTTP. API compatible for integration. Uniarch Client and Uniarch APP supported. Plug-in required live view via IE 10+, Chrome 45+, Firefox 52+, Edge 79+.

Pan & Tilt: Pan range 0°–355°, speed 17°/s–50°, preset speed 50°/s. Tilt range -15°–90°, speed 17°/s–50°, preset speed 50°/s. 20 preset positions. Home position supported.

Interface: Built-in microphone and speaker. Wi-Fi supported. Network: 1× RJ45 10/100 Mbps Base-TX Ethernet.

Certifications: CE EMC, FCC, RF FCC ID, CE RED. Safety: CE LVD. Environment: CE-RoHS, WEEE.

General: Power DC 5V/1.5A, USB Type-C interface. Dimensions Ø80×120 mm. Weight 0.23 kg. Operating environment -10°C to 50°C, ≤95% RH. Storage environment -10°C to 50°C, ≤95% RH. Reset button and call button supported. LED indicator: 1 red/blue.
