Hikvision 4MP Darkfighter Motorized Varifocal Bullet Network Camera DS-2CD2646G2HT-IZS(2.8-12mm)

Hikvision 4MP Darkfighter Motorized Varifocal Bullet Network Camera DS-2CD2646G2HT-IZS(2.8-12mm)

Security requirements and application settings vary. That's why Hikvision designs and tailors network cameras to meet various needs, from general video monitoring to video content analytics with deep learning algorithms and beyond.

By rendering high-quality images across a range of lighting conditions, minimizing storage and bandwidth requirements and providing data-powered situational awareness, Hikvision network cameras can help users make smart decisions. Our network cameras are the ideal choice for hundreds of application scenarios.

Features:

• High quality imaging with 4 MP resolution
• Excellent low-light performance via powered-by-DarkFighter technology
• Clear imaging against strong back light due to 120 dB WDR technology
• Efficient H.265+ compression technology
• Motorized varifocal lens for easy installation and monitoring
• Focus on human and vehicle classification based on deep learning
• Water and dust resistant (IP67) and vandal resistant (IK10)

Technical Specifications:

Camera

Image Sensor
1/3" Progressive Scan CMOS

Max. Resolution
2688 × 1520

Min. Illumination
Color: 0.001 Lux @ (F1.0, AGC ON), B/W: 0 Lux with IR

Shutter Time
1/3 s to 1/100,000 s

Day & Night
IR cut filter

Angle Adjustment
Pan: 0° to 355°, tilt: 0° to 90°, rotate: 0° to 360°

Lens
Lens Type
Varifocal lens, motorized lens, 2.8 to 12 mm

Focal Length & FOV
2.8 to 12 mm, horizontal FOV 105.4° to 34.3°, vertical FOV 56.1° to 19.3°, diagonal FOV 125.8° to 39.4°

Lens Mount
Ø14

Iris Type
Fixed

Aperture
F1.0

Depth of Field
1 m to ∞

DORI
Wide: D: 63.4 m, O: 25.2 m, R: 12.7 m, I: 6.3 m
Tele: D: 180.6 m, O: 71.7 m, R: 36.1 m, I: 18.1 m

Illuminator
Supplement Light Type
IR

Supplement Light Range
Up to 60 m

Smart Supplement Light
Yes

IR Wavelength
850 nm

Video
Main Stream
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)

Sub-Stream
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)

Third Stream
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
Third stream is supported under certain settings

Video Compression
Main stream: H.265, H.264, H.264+, H.265+
Sub-stream: H.265, H.264, MJPEG
Third stream: H.265, H.264
Third stream is supported under certain settings

Video Bit Rate
32 Kbps to 8 Mbps

H.264 Type
Baseline Profile, Main Profile, High Profile

H.265 Type
Main Profile

Bit Rate Control
CBR, VBR

Scalable Video Coding (SVC)
H.264 and H.265 encoding

Region of Interest (ROI)
1 fixed region for main stream and sub-stream

Audio
Audio Compression
G.711ulaw, G.711alaw, G.722.1, G.726, MP2L2, PCM, MP3, AAC-LC

Audio Bit Rate
64 Kbps (G.711ulaw/G.711alaw), 16 Kbps (G.722.1), 16 Kbps (G.726), 16 to 64 Kbps (AAC-LC), 32 to 192 Kbps (MP2L2), 8 to 320 Kbps (MP3)

Audio Sampling Rate
8 kHz, 16 kHz, 32 kHz, 44.1 kHz, 48 kHz

Environment Noise Filtering
Yes

Network
Protocols
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP

Simultaneous Live View
Up to 6 channels

API
Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP

User/Host
Up to 32 users, 3 user levels: administrator, operator, user

Security
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address)

Network Storage
NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)

Client
iVMS-4200, Hik-Connect, Hik-Central

Web Browser
Plug-in required live view: IE 10, IE 11
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+

Image Parameters Switch
Yes

Image Settings
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser

Day/Night Switch
Day, Night, Auto, Schedule

Image Enhancement
BLC, HLC, 3D DNR

SNR
≥ 52 dB

Wide Dynamic Range (WDR)
120 dB

Privacy Mask
4 programmable polygon privacy masks

Interface
Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port

On-Board Storage
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB

Audio
1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium
1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium

Alarm
1 input, 1 output (max. 24 VDC/24 VAC, 1 A)

Reset Key
Yes

Event
Basic Event
Motion detection (support alarm triggering by specified target types: human and vehicle), video tampering alarm, exception

Smart Event
Scene change detection

Linkage
Upload to FTP/NAS/memory card, notify surveillance center, send email, trigger alarm output, trigger recording, trigger capture, audible warning

Deep Learning Function
Face Capture
Yes

Perimeter Protection
Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human and vehicle)

General
Power
12 VDC ± 25%, 1.08 A, max. 13 W, Ø5.5 mm coaxial power plug, reverse polarity protection
PoE: IEEE 802.3at, Class 4, max. 15 W

Material
Front cover: Metal, body: Metal, bracket: Metal

Dimension
298 mm × 97.9 mm × 95.7 mm (11.8" × 3.9" × 3.8")

Package Dimension
385 mm × 190 mm × 180 mm (15.2" × 7.5" × 7.1")

Weight
Approx. 1490 g (3.3 lb.)

With Package Weight
Approx. 2349 g (5.2 lb.)

Storage Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

Startup and Operating Conditions
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)

General Function
Heartbeat, mirror, password reset via email, pixel counter, anti-banding

Language
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian

Approval
EMC
CE-EMC: EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013 + A1: 2019, EN 50130-4: 2011 + A1: 2014
IC: ICES-003: Issue 7
RCM: AS/NZS CISPR 32: 2015

Safety
CB: IEC 62368-1: 2014 + A11
CE-LVD: EN 62368-1: 2014/A11: 2017

Environment
CE-RoHS: 2011/65/EU
WEEE: 2012/19/EU
Reach: Regulation (EC) No 1907/2006

Protection
IP67: IEC 60529-2013, IK10: IEC 62262:2002
