Logitech Rally Board 65 Graphite 960-001751

Logitech Rally Board 65 Graphite 960-001751

Simplify the way you meet and collaborate. The 65-inch touchscreen enables a seamless collaboration experience in any environment. Enjoy quick and easy setup, AI-driven features, and flexible installation options.

Simple all-in-one solution: Everything you need to quickly add video to meeting rooms and open spaces. Experience all-in-one video conferencing that combines crystal clear video, powerful audio, and AI-driven features, all integrated into a single 65-inch touchscreen.

Built for flexibility: Rally Board 65 is designed for the way you meet. It can be deployed with the camera positioned above or below the screen, ensuring all participants maintain natural eye contact in any space.

Ready in no time: Set up right out of the box in just a few steps and minimize the need for onsite IT support. Included mounts and remote configuration mean you can get Rally Board 65 up and running in minutes.

Depth blur: Provides clear focus and helps eliminate distractions by using a depth-mapping sensor to distinguish between in-focus and out-of-focus areas, delivering a more natural depth effect compared to standard background blur settings

RightSight 2: Optimize participant framing and image processing to deliver clear, crisp visuals for more productive person-to-person interactions.

RightSound 2: Minimizes background noise, reduces reverb, and balances voices, delivering crisp audio and eliminating distracting background noise.

Specifications:

Rally Board 65 (device only)

• Width: 1500 mm
• Height: 989 mm
• Depth: 76 mm
• Weight: 46 kg
• VESA Standard MIS F: 400 x 400 mm and 400 x 200 mm

Rally Board 65 with included table stand

• Width: 1500 mm
• Height: 1051 mm
• Depth: 395 mm
• Weight: 50 kg

General

• Built-in Components: Front microphone array, digital PTZ camera, dual full-range ported speakers, dual tweeters, ultrasonic emitter, cable management and retention system, integrated motorized privacy shutter, depth mapping camera, radar motion sensing, and environmental sensors
• Support for 2nd display, up to UHD 4K60 (3840 x 2160)
• Automatic motorized privacy shutter
• HDMI ingest at up to 4K60 (3840 x 2160) resolution
• Network Protocol Support: IPv4, IPv6
• Proxy support: IP-based proxy, FQDN-based proxy, proxy using PAC file

System Requirements

• 100 - 240v
• Internet Connection: Wired or wireless
• Room solution software license (not included)

Display

• 65-inch LCD screen
• IR-based touch with 20 points of touch
• UHD 4K (3840 x 2160) screen resolution
• 16:9 aspect ratio
• Anti-glare coating
• Anti-fingerprint coating
• Contrast ratio: 5000:1 Typical
• Brightness: 400 nits Typical

Camera

Main camera

• Imaging sensor: 1-inch, 20.3MP
• Resolution: 4K, 1440p, 1080p, 900p, 720p, and SD at 30fps
• Automatic motorized tilt based on device orientation
• Zoom: 4X HD digital zoom
• Distortion-corrected field of view
• Diagonal: 115.7°
• Horizontal: 103.3°
• Vertical: 60.7°
• Depth mapping camera
• Diagonal Field of View: 145°
• Horizontal Field of View: 121°

Speakers

Dual full-range ported speakers

• Driver: 2 x 70 mm
• Sensitivity: 89 dB SPL at 1W/0.5 m
• Rated Power: 8W
• THD at 1W, 1 kHz <2%

Dual high-frequency tweeters

• Driver: 2 x 31 mm
• Sensitivity: 93 dB SPL at 1W/0.5 m
• Rated Power: 8W
• THD at 1W, 4 kHz < 2%

Microphones

Front microphone array

• Frequency Response: 90Hz-16KHz

• Sensitivity: -36 dB FS +/-1 dB @ 1 Pa
• Microphone data rate output: 48KHz
• Pickup Range: Up to 7 m
• RightSound 2
• AI Speech Enhancement removes transient and stationary noise
• Beamforming with AI Beam Selection
• AI Speech Detection
• AI Direction of Speech
• Acoustic Echo Cancellation and Residual Echo Suppression

Sensors

• Temperature
• Humidity
• tVOC (Total volatile organic compounds)
• Carbon dioxide
• PM2.5
• PM10
• Radar
• Ambient light
• For the latest information on certification and compatibility, see www.logitech.com/support/vc-certifications

Interfaces

• 1 x HDMI Out: up to 4K60
• 1 x HDMI In: up to 4K60
• USB-A: 3 x USB 3.1
• USB-C: 1 x Type C USB 3.1 with DP Alt Mode
• Line-Out: 3.5 mm line-level audio output
• Network: 10/100/1G Ethernet
• Wi-Fi: 802.11a/b/g/n/ac/ax
• Bluetooth: Bluetooth Low Energy
• EXT: RJ45 reserved for future use

Power and Cables

• Power supply: Built-in auto-sensing 100-240V
• AC Cable: 3 m

Environmental

• Operating temperature: 0-35 °C
• Storage temperature: -40-60 °C
• Humidity: 10-95%

Security

• File-based encryption: AES-256
• Data Encryption: Symmetric Keys, PKI
• Device Identity: Protected by device attestation
• Device Access: Authenticated using API
• Key Protection: Arm TrustZone, RPMB

Accessories

• Rally Board 65 Cart
• Active USB Cable

What's in the box:

• Main device
• Tabletop legs (x2)
• Power cord
• Stylus (x2)
• VESA 100 PC mount
• Cable hook
• Assembly hardware and tools
• Documentation
