Synology RS2825RP+ 16-Bay 8GB DDR4 3U NAS Rack

Synology RS2825RP+ 16-Bay 8GB DDR4 3U NAS Rack

Designed for small businesses and remote office deployments, the RackStation RS2825RP+ 16-Bay NAS Enclosure from Synology is a versatile storage system for central data storage and sharing, endpoint and server backup, surveillance management, and other business applications. This unit has 16 drive bays, each of which natively supports 3.5" SATA hard drives, as well as 2.5" SATA hard drives and SSDs. Should users need to expand the overall capacity of their RS3618xs, the optional RX1225RP expansion unit offers an additional 12 drive bays.

• 16 x 2.5/3.5" SATA III Drive Bays
• 3.35 GHz AMD Ryzen V1780B Quad-Core CPU
• 8GB of DDR4 ECC RAM
• 1 x 10GbE RJ45 | 2 x 1GbE RJ45
• 2 x USB-A 3.2 Gen 1 | 1 x Mini-SAS HD
• RAID 0, 1, 5, 6, 10, Hybrid, Basic, JBOD
• Read Speeds up to 3519 MB/s
• Hardware Encryption
• 1 x PCIe 3.0 x8/x4 Expansion Slot
• Dual Redundant 500W Power Supplies

The RackStation RS2825RP+ is powered by a 3.35 GHz AMD Ryzen V1780B Quad-Core processor and 8GB of DDR4 ECC RAM, which can be upgraded to a total of 32GB by installing two 16GB modules into the available memory slots. Also featured are two USB-A 3.2 Gen 1 ports and network connectivity is achieved using one 10GbE RJ45 port or two Gigabit Ethernet RJ45 ports with failover support, which help to provide redundancy in the case of a LAN connection malfunction occuring on one port. In addition, link aggregation helps to increase connection speeds beyond the limits of a single network port or cable. If you're looking to expand this NAS, there is a PCIe Gen 3.0 x8/x4 slot that supports an M.2 SSD & 10GbE adapter card, an M.2 SSD adapter card, a 25GbE NIC, or a 10GbE NIC.

The RackStation RS2825RP+ runs on the DiskStation Manager (DSM) operating system, which helps simplify managing your NAS, as well as accessing and sharing data. A variety of RAID modes are supported, which help provide users with data redundancy, speed, or a combination of both. Supported RAID modes include RAID 0, 1, 5, 6, 10, Basic, and Synology Hybrid RAID. For those who do not require a RAID, JBOD is also available, allowing each drive bay to be individually utilized.

Synology has engineered the RackStation RS2825RP+ to be energy efficient. Not only does it offer three 80 x 80mm fans to help keep the system running cool, the server supports numerous scheduled power on / off cycles and hard drive hibernation to further minimize power consumption and operation expenses. The RackStation RS2825RP+ operates on 100-240 VAC at 50/60 Hz with dual redundant 550W power supplies and includes an accessory pack and two AC power cords. Protection is provided by a limited three-year hardware warranty.

Built for Reliability

Redundant Power

Redundant power supplies ensure maximum server uptime by preventing single-point power failures.

High Availability

Pair two identical devices with Synology High Availability and enable automatic minute-level failover between both devices in the event one server fails.

Network Redundancy and Load Balancing

One built-in 10GbE and dual 1GbE ports can be bonded with Link Aggregation to enable automatic network failover and load balancing.

Accommodates Future Expansion

Flexibly configure the RS2825RP+ to meet evolving needs through faster networking, local SSD cache, or increased storage.

Flexible Networking Options

Improve I/O or add redundancy with 10GbE or 25GbE SFP+/SFP28 networking, or 1GbE/10GbE Ethernet (RJ45) networking.

SSD Cache

Reduce latency and increase IOPS in HDD arrays with the performance boost of SSD caching.

Storage Expansion

• Expand compatibility to 28 drive bays with one optional RX1225RP expansion unit.
• Intuitive Storage for On-Site and Remote Teams
• Provide secure and convenient cross-platform tile access, sharing, and synchronization across multiple locations.
• A Secure Private Cloud Solution for Enterprise Collaboration

A Private Cloud Suite for File Sharing

Empower your entire organization with streamlined access, sharing, and syncing of data from any location. Establish granular control over file and folder access and sharing permissions. Maintain a comprehensive audit trail of file activities and track changes to file-share settings with detailed records.

Multi-Platform Support

Access personal and shared data from mobile apps, desktop clients, web browsers, or another Synology system. Any changes you make are automatically synced to other devices as soon as they are connected.

Collaboration In a Secure Cloud

Enhance workplace collaboration with Synology's productivity solutions. Create, edit, and share documents across teams in real time. Host an on-premises mail server to provide web-based email access while maintaining full data ownership. Additionally, stay connected through secure one-on-one chats, public channels, encrypted private channels, and group conversations.

Efficient Multi-Site Synchronization

Cloud-Powered Multi-Site Syncing
Empower global workflows with high-speed access to data from anywhere in your network. Synology's hybrid cloud solution caches frequently used files locally for rapid access, while less frequently accessed data is stored in the cloud, reducing your on-site storage requirements.

NAS-to-NAS Synchronization

Automate site-to-site data synchronization for better team workflows. Options for one-way or two-way syncing keeps files and folders up-to-date across every data site.

Sync to Public Cloud Providers

Connect seamlessly to public cloud services including Amazon S3, BackBlaze B2, Dropbox, Google Cloud Storage, Microsoft Azure, and OpenStack Swift. Multiple protocol support, client-side encryption, and customizable sync and bandwidth controls enable efficient storage management across various platforms.

Comprehensive Backup Solutions

PC, Mac, Server, VM, and NAS/SAN Protection

Securely back up a wide range of systems including Windows, Mac, and Linux endpoints, VMware and Hyper-V virtual machines, and Synology servers. Expand protection to physical servers running Windows or Linux, as well as storage solutions such as Nutanix Files, NetApp ONTAP, and Windows Server with VSS (Volume Shadow Copy Service). Built-in de-duplication technology optimizes storage efficiency, while multi-versioning capabilities provide flexible restoration options.

Microsoft 365 and Google Workspace

Centralize backups of Microsoft 365 and Google Workspace data to protect cloud data from accidents and simplify compliance with data retention policies. Schedulable backups, flexible file versioning, and block-level de-duplication ensure flexibility and storage and bandwidth savings.

Advanced Data Protection and Recovery

Efficient and Reliable Synology System Backup

Back up entire systems or all data, applications, and configurations to a wide range of storage destinations, including Synology C2 Storage. In case of data loss, quickly restore complete systems through bare-metal recovery or retrieve individual files as needed. Advanced features including automated scheduling, granular access controls, end-to-end encryption, data de-duplication, and multi-version retention empower you to create the optimal backup plan for your data deployment.

Tamper-Proof Protection with Immutable Snapshots

Safeguard critical LUNs and shared folders with automated immutable snapshots backed by custom retention policies. Built-in support for offsite replication further ensures robust business continuity.

Surveillance

Synology Surveillance Station

Protecting your business has never been easier with centralized management, support for over 8,700 IP camera models, and remote monitoring and playback. Synology's scalable video management system provides all the tools you need for live monitoring, investigation, management, and backup.

Dual Recording to the Cloud

Secure your surveillance footage with robust cloud backup that supports end-to-end encryption. The cloud-based surveillance backup solution safeguards your Surveillance Station recordings, allowing you to access, view, share, and download footage through a convenient web portal, ensuring your data remains available even if your on-premises system is compromised.

Centralized Monitoring and Management

Monitor and manage your Synology fleet from a central interface, on-prem, or in the cloud.

Central Management System

Manage Synology servers from a central console using group policies, task delegation, batch updates, and more.

Active Insight

Monitor your global Synology fleet's performance, backup status, login activity, and more with the power of the cloud.

Specifications:

RAID: Yes: Supported RAID Modes: 0 / 1 / 5 / 6 / 10 / JBOD / Basic / Hybrid

Number of Bays: 16x 2.5"/3.5" SATA III (Hot-Swap)

Inputs/Outputs:

• 1x RJ45 10GbE
• 2x RJ45 Gigabit Ethernet
• 2x USB-A 3.0 / 3.1/3.2 Gen 1
• 1x Mini SAS (Unspecified)
• 1x 9-Pin Serial

CPU: Quad-Core: 3.35 to GHz

Processor: AMD Ryzen V1780B

Memory: 8 GB ECC DDR4

RAM Configuration / Capacity: 1x User-Replaceable 8 GB / 2 Slots Supporting up to 32 GB

Transfer Rates: 3519 MB/s (Read), 1790 MB/s (Write)

Media Card Slots: No

PCI Expansion: 1x PCIe 3.0 x8 (x4 Electrical)

Link Aggregation and Failover Support: Yes

iSCSI Support: Yes: 128 LUN / 64 Target

Installed Operating System: No

OS Compatibility: Windows, macOS, Linux

Mobile App Compatible: No

Encryption: Yes, AES-NI (Hardware-Based)

Security Features: No

VPN Connections: 12 (Server)

Input Power: 100 to 240 VAC, 50 / 60 Hz

Power Consumption: 134.48 W (Typical), 50.81 W (Standby)

PSU: 2 x 550 W (Supports Redundancy)
