Hikvision Analogue Gooseneck Paging Microphone DS-QAE0MG0G1

Hikvision Analogue Gooseneck Paging Microphone DS-QAE0MG0G1

Features:

• High SNR and balanced frequency response sound inlet basket
• Equipped with high sensitivity, low noise pre-amplification circuit
• The pickup part adopts the droplet shape design
• Support 12 VDC power supply and 48 V phantom power supply

Technical Specifications:

Microphone

Type
Electret

Directivity
Cardioid

Pickup Range
0.5 m

Frequency Response
20 Hz To 20 kHz

Sensitivity
-30 dB (0 dB = 1 V/Pa @ 1 kHz)

Signal-To-Noise Ratio (SNR)
70 dB

Dynamic Range
80 dB

Acoustic Overload Point (AOP)
104 dB

Equivalent Noise Level (LEQ)
≤ 24 dB

Sound Inlet Basket Diameter
Ø9.7 mm

Gooseneck Adjustment Angle
360°

Input Current
≤ 10 mA

Interface

Microphone Interface
XLR Connector (Balanced)

LED Indicators

• Key Indicator
• Sound Inlet Basket Indicator

Speaker

Impedance
120 Ω

Power

Power Supply

• 48 V Phantom Power
• 12 V DC

General

Dimensions

• Base: 35 × 98 × 119 mm
• Gooseneck Length: 409 mm

Weight
Approx. 0.59 kg

Package Dimensions
485 × 156 × 140 mm

Operating Temperature
Up To 35 °C (95 °F)

What's in the Box:

• Microphone × 1
• Power Supply × 1 (12 V DC)
• XLR Cable × 1
• Regulatory Compliance And Safety Information × 1
