Hikvision 40W 1-Zone Network Amplifier DS-QAE1A40G1-VB

Hikvision 40W 1-Zone Network Amplifier DS-QAE1A40G1-VB

Features:

• Rated Power: 40 W, 1 Zones
• Audio input: USB/Bluetooth/MIC/RCA
• Support volume and content adjustment
• Support schedule/live/emergency broadcast, alarm linkage, TTS

Technical Specifications:

Function

Audio Bit Rate

• G.711uLaw (64 Kbps)
• G.711aLaw (64 Kbps)
• MP3 (32 Kbps To 320 Kbps)

Sampling Bit Width
16 Bits

Speech Synthesis Languages

• English
• Russian
• Spanish
• Japanese
• Thai
• Portuguese (Brazil)
• Korean
• French

Protection Functions

• Short Circuit Protection
• Overcurrent Protection
• Over Temperature Protection
• Anti-Static Electricity Protection
• Surge Protection
• Electrical Shock Protection

Network

Network Protocols
IPv4, HTTP, HTTPS, SSL/TLS, DNS, NTP, TCP, UDP, IGMP, ICMP, DHCP, ARP, SSH

Interface Protocol (API)
ISAPI, ISUP, RTP

Audio

Rated Power
40 W

Rated Voltage
24 V DC

Frequency Response
80 Hz To 20 kHz (±3 dB)

THD And SNR

• THD: ≤ 1%
• SNR: ≥ 100 dB

Interface

Alarm Interface

• 1 × Alarm Input
• 1 × Alarm Output

Ethernet Interface
1 × RJ45 10/100 Mbps Adaptive Ethernet Port

Local Storage
Built-In 4 GB eMMC (Audio File Storage: 1 GB)

Audio Input

• MIC 1: -28 dBV, 2.57 KΩ, Unbalanced, 6.35 mm Jack (Supports Dynamic Microphone)
• 1 × USB 2.0
• 1 × RCA In: 0 dBV, 5 KΩ, Unbalanced
• Bluetooth Supported

Audio Output

• 1 × Constant Voltage Output (100 V COM)
• 1 × RCA Out: 0 dBV, 100 Ω, Unbalanced
• RCA Cascading: Supports Cascade Of Up To 3 Amplifiers

LED Indicators

• Power Indicator (Solid White): Device Operating Normally
• USB Indicator (Solid White): USB Mode Active
• Bluetooth Indicator (Solid Blue): Bluetooth Mode Active

Volume Controls

• MIC Volume Knob × 1
• Volume Knob × 1

USB Support

• USB 2.0 / USB 3.0
• File Format: FAT32
• Maximum Capacity: 128 GB
• Maximum File Size: 4 GB

Power Interface
Ø2.0 mm Connector

General

Material
Plastic

Color
White

Supported Languages
41 Languages Including:
English, French, Spanish, German, Italian, Japanese, Thai, Russian, Portuguese (Brazil), Arabic, Bulgarian, Czech, Danish, Greek, Spanish (Mexico), Estonian, Persian, Finnish, Hebrew, Croatian, Hungarian, Indonesian, Kazakh, Korean, Kyrgyz, Lao, Lithuanian, Latvian, Dutch, Norwegian, Polish, Portuguese, Romanian, Slovak, Slovenian, Serbian, Swedish, Turkish, Ukrainian, Uzbek, Vietnamese

Dimensions
190.8 × 230.8 × 51.2 mm

Weight
Approx. 1496.2 g

Package Dimensions
362 × 280 × 100 mm

Package Weight
Approx. 2456.2 g

Bluetooth Version
Bluetooth 5.0 (Up To 10 m Range)

Operating Temperature
-10 °C To 55 °C (14 °F To 131 °F)

Operating Humidity
≤ 90% (Non-Condensing)

Power Consumption

• Standby Consumption: 4.5 W
• Maximum Working Consumption: 45 W

What's in the Box:

• 1-Zone Network Amplifier × 1
• Power Adapter × 1
• Power Cord × 1
• Regulatory Compliance And Safety Information × 1
