Hikvision 20W Analog Cabinet Speaker DS-QAE0120G1R

Hikvision 20W Analog Cabinet Speaker DS-QAE0120G1R

Features:

• 5.25′′ × 1
• Rated Power: 70 V: 5 W/10 W/15 W/20 W, 100 V: 5 W/10 W/15 W/20 W
• Sensitivity(1 m, 1 W): 90 dB ± 3 dB
• Max. SPL: 103 dB
• Frequency Response: 130 Hz to 17.5 kHz

Technical Specifications:

Speaker

Rated Power

• 70 V: 5 W / 10 W / 15 W / 20 W
• 100 V: 5 W / 10 W / 15 W / 20 W

Impedance: 8 Ω
Maximum Acoustic Pressure: 103 dB SPL
Sensitivity (1 m, 1 W): 90 dB ± 3 dB
Direction: All Directions
Frequency Response: 130 Hz to 17.5 kHz

Speaker Unit

• 1 × 5.25″

Coverage Angle

• Horizontal: 135°
• Vertical: 130°

Interface

Audio Input

• 1 × Fixed Pressure Input (100 V)
• 1 × Fixed Pressure Input (70 V)
• 1 × Fixed Resistance Input (8 Ω)

General

Material: Main Body and Front Cover: Plastic; Bracket: Metal
Operating Temperature: -30 °C to 60 °C
Operating Humidity: <90% (Non-Condensing)
Colour Options

• White
• Black

Dimensions: 268.4 × 180.4 × 125.12 mm
Product Weight: Approx. 1.5 kg

Packaging

Package Dimensions: 340 × 306 × 180 mm
Package Weight: Approx. 2 kg

What’s in the Box:

• Device × 1
• U-Shaped Bracket × 1
• Screw Pack × 1
• Installation Sticker × 1
• Regulatory Compliance and Safety Information × 1
