Aerocool APNX V1 White Mid Tower ATX Case APCM-VI01443.21

Aerocool APNX V1 White Mid Tower ATX Case APCM-VI01443.21

This mid-tower PC case combines a stylish black color with excellent airflow. It features a 45° angled intake design, a dual-chamber structure, and comes standard with four cooling fans. Combining high cooling performance with ease of assembly, it's an ideal choice for gamers.

Features:

Beautiful appearance and panoramic view: The front and side panels are made entirely of tempered glass, providing a panoramic view of the internal configuration at a glance. The understated all-black finish gives the entire system a sleek look.

Airflow design optimized for cooling: In addition to a 45° angled intake and dual-chamber structure, it comes standard with four cooling fans, significantly improving the cooling efficiency of the GPU and CPU. It supports up to 10 fans and large radiators, maintaining stable operation even under heavy load.

Flexible internal design: Supports GPUs up to 395mm and CPU coolers up to 170mm. Adjustable motherboard position and ample internal space allow for diverse configurations and the installation of large components.

Comfortable maintenance and assembly environment: Quick-release cooling brackets and hinged storage brackets make assembly and parts replacement smooth. Magnetic filters placed throughout make cleaning easy.

Smart cable management features: 90mm of cable space, Velcro channels, and rubber pass-through construction allow for neat and tidy cable management. Height and angle adjustable mounts are included as standard to support even heavy GPUs.

Technical Specifications:

Color White
Case Type Mid-tower
Material Steel, Plastic, Tempered Glass

Dimensions
Product Size (W×D×H) 290×500×485.5mm

Compatibility
Compatible Motherboards ATX/Micro-ATX/Mini-ITX
Compatible Power Supply ATX

Drive Bays
Drive Bays 2 x 2.5/3.5 inch shared, 4 x 2.5 inch

Expansion
Expansion Slots 7

Front I/O Interfaces
Interfaces USB 10Gbps Type-C x 1, USB 5Gbps Type-A x 2, Audio & Mic

Cooling Support

Included Case Fans
Front (Right) 120mm x 3
Rear 120mm x 1

Compatible Case Fans
Front (Right) 120mm x 3 / 140mm/160mm x 2
Top/Bottom 120mm x 3 / 140mm x 2
Rear 120mm x 1

Radiator Support
Compatible Radiators Front (right side), Top, Bottom: 120/140/240/280/360mm
Rear: 120mm
(Note: If the motherboard is installed in the upper position, the 140/280mm bottom radiator is not recommended)

Clearance
GPU Length Max. 395mm
CPU Cooler Height Max. 170mm
PSU Length Max. 220mm
Cable Management Depth 90mm
