APC NetBotz Rack Monitor 750 NBRK0750

APC NetBotz Rack Monitor 750 NBRK0750

The NetBotz Rack Monitor 750 provides integrated surveillance,sensing, access control, and advanced alerting for IT environmentsof all sizes, from single-rack edge networks to large data centers. The NetBotz 750 offers an active monitoring solution designed to protect against environmental threats and unauthorized access risks that can cause downtime to IT infrastructure, in both Edge Compute and Data Center environments. With its integrated suite of sensors, access control pods, and the newly introduced HD Camera Pod 165, the NetBotz 750 safeguards environments with surveillance and flexible alerting based on user-definable thresholds. Compute is quickly moving closer to where it is used at the Edge, increasing the risks of water damage, high temperature & humidity, fire or other conditions bringing down business-critical applications. Intentional or malicious access events not only threaten compute availability, but also leave enterprises vulnerable to costly compliance violations. The NetBotz 756 provides integrated sensing, surveillance, and badged rack-access control to help mitigate these risks through a wide array of compatible sensors, camera clip capture and storage, and configurable alarming.

Technical Specifications:

Component Type
Industrial rack PC

Range of Product
NetBotz

Number of Rack Units
1U

Communication Port Protocols
A-Link
DHCP
HTTPS
IPv4
SNMP v1
SNMP v3
SSH v2
TCP/IP

Provided Equipment
Rack mounting brackets
Temperature/humidity sensor
USB cable

Product Compatibility
Rack Sensor Pod 150
Room Sensor Pod 155

General Specifications
Camera Frame Rate
Up to 30 fps

Display Resolution
Up to 1280 × 1024

Universal Sensors Supported
0–5V
Door contact (dry contact)
Humidity
Smoke
Fluid spot leak
Temperature
Vibration

Number of Universal Sensor Ports
6

Number of Sensor Pods Supported
12

Number of Universal Sensors Supported
78

Number of Supported Cameras
4

Physical Specifications
Colour
Black

Dimensions (H × W × D)
4.3 cm × 43.2 cm × 17.8 cm

Net Weight
2.45 kg

Mounting Location
Front or rear

Mounting Preference
No preference

Mounting Mode
Rack-mounted

Mounting Position
Horizontal

Conformance
Standards
CSA C22.2 No. 60950-1-03
FCC Part 15 Class A
ICES-003
UL 60950-1

Product Certifications
2014/30/EU
AS/NZS 3548 (C-Tick) Class A
CE
EMC Directive 2004/108/EC
VCCI Class A

Environmental Specifications
Operating Temperature
0°C to 40°C

Operating Altitude
0 to 10,000 ft

Operating Relative Humidity
0% to 95%

Storage Temperature
-15°C to 65°C

Storage Altitude
0 to 15,240 m

Storage Relative Humidity
0% to 95%

Communications & Management
Communication Network Type
RJ45 10/100/1000 Base-T
