Yamaha PA2120 120W Power Amplifier

Yamaha PA2120 120W Power Amplifier

Yamaha’s PA2120 is a 2-channel, 120-watt-per-channel power amp for everyday playback. Its energy-efficient class-D amplifier provides up to 120 watts of power to one stereo or two mono line inputs. The PA2120 features an intelligent protection function, handling power efficiently and safely to ensure long-lasting performance. Best of all, the PA2120 comes packed in a convenient 1U rack-size metal housing, enabling easy and reliable integration into any setup.

Designed for Effortless Everyday Use

The MA and PA series power amplifiers offer powerful features in compact, durable metal chassis. They are designed for easy, intuitive operation that makes specialized training or audio experience unnecessary. For example, the output volume knob has been made the focus of the front panel design, enhancing day-to-day operability while minimizing the possibility of error. No special software, programming or equipment is required for installation or setup. Anyone can quickly and easily set up a system that will deliver the best possible sound for a wide range of applications.

Features:

• 2-channel, 120W per-channel power amplifier
• Perfect for music playback applications
• Lo-Z (120W x 2 channels) and Hi-Z (200W x 1-channel) functionality
• Built-in highpass and lowpass filter
• Compact 1U rack size fits in nearly any setup
• Conventional cooling system bottom-to-top airflow
• Speaker EQ optimum for Yamaha VXC/VXS series speakers
• Yamaha Eco Product and Energy Star certified with efficient class-D amplifier

Specifications:

Product: Yamaha PA2120

Amplifier class: D

Total Harmonic Distortion (THD): 0.2%

RMS power output per channel (4 Ohm): 120 W

Speakers connectivity type: Euroblock

AC input voltage: 100, 120, 230-240 V

AC input frequency: 50 - 60 Hz

Power consumption (typical): 60 W

Width: 480 mm

Depth: 379 mm

Height: 45 mm
